SMC Air Cylinder: 32 mm Bore Dia, 145 MPa Max Op Pressure, 1/8 in Rc, Rubber Cushion
The SMC MKB32-20RZ is a double-acting rotary clamp cylinder with a 32 mm bore diameter, featuring a magnetic piston and a basic design with a female threaded body. It operates with a rubber cushion and has a maximum…
SKU 3G-OTH-162454
Need installation or engineering help?
Ask a question
Product Description
The SMC MKB32-20RZ is a double-acting rotary clamp cylinder with a 32 mm bore diameter, featuring a magnetic piston and a basic design with a female threaded body. It operates with a rubber cushion and has a maximum operating pressure of 145 MPa, with a 1/8 in Rc port size. This metric cylinder is part of SMC's rotary clamp cylinder product type.
Frequently Asked Questions
What is the SMC MKB32-20RZ rotary clamp cylinder used for?
The SMC MKB32-20RZ is a double-acting rotary clamp cylinder used in automated workholding, assembly fixtures, and material handling systems. Its 32 mm bore and magnetic piston enable position sensing, while the rubber cushion reduces end-of-stroke impact in industrial applications.
What are the specifications of the SMC MKB32-20RZ?
The SMC MKB32-20RZ has a 32 mm bore diameter, 145 MPa maximum operating pressure, 1/8 in Rc port size, and a rubber cushion. It is a double-acting, basic-type cylinder with a female threaded body and metric design, including a magnetic piston for position sensing.
Where to buy the SMC MKB32-20RZ worldwide?
3G Electric supplies the SMC MKB32-20RZ rotary clamp cylinder to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact our team for a quote and lead time on this pneumatic component.
How to select the correct SMC rotary clamp cylinder for an application?
To select the correct SMC rotary clamp cylinder, match bore size (32 mm), stroke length, and operating pressure (145 MPa max) to your clamping force and space constraints. Verify port size (1/8 in Rc) and cushion type (rubber) for your pneumatic circuit. Consult SMC technical data for torque and rotation angle.
Used in
Common applications for SMCSMC Products
3G Electric supplies SMC rotary clamp cylinders. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
