SMC Air Cylinder: 40 mm Bore Dia, 145 MPa Max Op Pressure, 1/8 in Rc, Rubber Cushion - Rotary Clamp Cylinders
SMCRotary Clamp Cylinders

SMC Air Cylinder: 40 mm Bore Dia, 145 MPa Max Op Pressure, 1/8 in Rc, Rubber Cushion

The SMC MKB40-30RZ is a double-acting rotary clamp cylinder with a 40 mm bore diameter, featuring a magnetic piston and a basic, metric, female threaded body design. It operates with a rubber cushion and has a…

SKU 3G-OTH-162459

Brand
SMC
Item
Air Cylinder: 40 mm Bore Dia, 145 MPa Max Op Pressure, 1/8 in Rc, Rubber Cushion
Category
Rotary Clamp Cylinders
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
MKB40-30RZ
Type
Rubber Cushion, Metric
Rc
1/8 in
MPa Max Op Pressure
145
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC MKB40-30RZ is a double-acting rotary clamp cylinder with a 40 mm bore diameter, featuring a magnetic piston and a basic, metric, female threaded body design. It operates with a rubber cushion and has a maximum operating pressure of 145 MPa, with a 1/8 in Rc port size.

Frequently Asked Questions

What is the SMC MKB40-30RZ rotary clamp cylinder used for?

The SMC MKB40-30RZ is a double-acting rotary clamp cylinder used in automated workholding, assembly, and material handling applications. Its 40 mm bore and magnetic piston enable precise position sensing, while the rubber cushion reduces end-of-stroke impact in industrial machinery.

What are the specifications of the SMC MKB40-30RZ?

The SMC MKB40-30RZ has a 40 mm bore, double-acting operation, 145 MPa max operating pressure, 1/8 in Rc port size, and a rubber cushion. It features a magnetic piston, basic metric design, and female threaded body. The manufacturer part number is MKB40-30RZ.

Where to buy the SMC MKB40-30RZ worldwide?

3G Electric supplies the SMC MKB40-30RZ rotary clamp cylinder to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this pneumatic component.

How to select the right SMC rotary clamp cylinder?

Select an SMC rotary clamp cylinder by matching bore size, stroke, operating pressure, and port size to your application. For the MKB40-30RZ, confirm 40 mm bore, 145 MPa max pressure, and 1/8 in Rc ports suit your pneumatic system. Verify cushion type and mounting style for reliable operation.
