SPEEDAIRE Cylinder Mounting Hardware: Clevis, Fits 80 mm Bore Dia, 95 mm Overall Lg
The SPEEDAIRE Cylinder Mounting Hardware: Clevis (SKU 5VMF5) is a pivot and eye mounting accessory designed for pneumatic cylinders. This clevis bracket is constructed from aluminum and fits cylinders with an 80 mm…
SKU 3G-OTH-142851
Need installation or engineering help?
Ask a question
Product Description
The SPEEDAIRE Cylinder Mounting Hardware: Clevis (SKU 5VMF5) is a pivot and eye mounting accessory designed for pneumatic cylinders. This clevis bracket is constructed from aluminum and fits cylinders with an 80 mm bore diameter, with an overall length of 95 mm. It is manufactured by SPEEDAIRE under part number 5VMF5.
Frequently Asked Questions
What is SPEEDAIRE 5VMF5 clevis bracket used for?
The SPEEDAIRE 5VMF5 clevis bracket is a pivot and eye mounting accessory for pneumatic cylinders. It connects the cylinder rod to a machine component, allowing angular movement. This aluminum clevis fits 80 mm bore cylinders and is commonly used in industrial automation, packaging, and material handling systems.
What are the specifications of SPEEDAIRE 5VMF5 clevis bracket?
The SPEEDAIRE 5VMF5 clevis bracket is made of aluminum, fits cylinders with an 80 mm bore diameter, and has an overall length of 95 mm. It is a clevis-type mounting bracket designed for pneumatic cylinder applications. The manufacturer part number is 5VMF5.
Where to buy SPEEDAIRE 5VMF5 clevis bracket worldwide?
3G Electric supplies the SPEEDAIRE 5VMF5 clevis bracket worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this pneumatic cylinder mounting hardware.
How to install SPEEDAIRE 5VMF5 clevis bracket on a cylinder?
To install the SPEEDAIRE 5VMF5 clevis bracket, align the clevis pin holes with the cylinder rod eye and insert the pin. Secure with a retaining ring or cotter pin. Ensure the bracket rotates freely without binding. Torque fasteners to manufacturer specifications for the cylinder and application.
