SPEEDAIRE Cylinder Mounting Hardware: Clevis, Fits 40 mm Bore Dia, 56 mm Overall Lg - Pivot & Eye Mounting Hardware
SPEEDAIREPivot & Eye Mounting Hardware

SPEEDAIRE Cylinder Mounting Hardware: Clevis, Fits 40 mm Bore Dia, 56 mm Overall Lg

The SPEEDAIRE Cylinder Mounting Hardware: Clevis (SKU 5VMG5) is a Piston Rod Swivel Eye Mount made of aluminum. It features an M12x1.25 thread and fits a 40 mm bore diameter with a 56 mm overall length. This pivot…

SKU 3G-OTH-142858

Brand
SPEEDAIRE
Item
Cylinder Mounting Hardware: Clevis, Fits 40 mm Bore Dia, 56 mm Overall Lg
Category
Pivot & Eye Mounting Hardware
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SPEEDAIRE
Manufacturer Part Number
5VMG5
Type
Fits 40 mm Bore Dia, Aluminum, 5VMG5
Overall Lg
56 mm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SPEEDAIRE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SPEEDAIRE Cylinder Mounting Hardware: Clevis (SKU 5VMG5) is a Piston Rod Swivel Eye Mount made of aluminum. It features an M12x1.25 thread and fits a 40 mm bore diameter with a 56 mm overall length. This pivot and eye mounting hardware is designed for use with SPEEDAIRE cylinders.

Frequently Asked Questions

What is SPEEDAIRE 5VMG5 clevis mounting hardware used for?

The SPEEDAIRE 5VMG5 clevis is a piston rod swivel eye mount used to attach a cylinder rod to a machine component, allowing angular movement. It is designed for pneumatic cylinders with a 40 mm bore diameter and is made of aluminum for lightweight corrosion resistance.

What are the specifications of the SPEEDAIRE 5VMG5 clevis?

The SPEEDAIRE 5VMG5 clevis has an M12x1.25 thread, fits a 40 mm bore diameter, and has a 56 mm overall length. It is made of aluminum and is classified as a piston rod swivel eye mount. The manufacturer part number is 5VMG5.

Where to buy SPEEDAIRE 5VMG5 clevis worldwide?

You can source the SPEEDAIRE 5VMG5 clevis through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive the correct pivot and eye mounting hardware for your application.

How to install the SPEEDAIRE 5VMG5 clevis on a cylinder?

To install the SPEEDAIRE 5VMG5 clevis, thread it onto the cylinder rod using the M12x1.25 thread. Ensure the clevis pin aligns with the mating component. Tighten securely but avoid over-torquing the aluminum body. Always follow the cylinder manufacturer's guidelines for proper installation.
