SQUARE D Miniature Circuit Breaker: 20 A, 120/240V AC, Single Phase, 10kA at 120/240V AC - HOM Series, Plug-In Square D Miniature Circuit Breakers
SQUARE DHOM Series, Plug-In Square D Miniature Circuit Breakers

SQUARE D Miniature Circuit Breaker: 20 A, 120/240V AC, Single Phase, 10kA at 120/240V AC

The SQUARE D HOMT2020220 is a 20 A, single-phase miniature circuit breaker from the HOM Series, designed for plug-in use with Homeline Load Centers. It has a 120/240V AC voltage rating and a maximum AIR rating of…

SKU 3G-OTH-20870

Brand
SQUARE D
Item
Miniature Circuit Breaker: 20 A, 120/240V AC, Single Phase, 10kA at 120/240V AC
Category
HOM Series, Plug-In Square D Miniature Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
HOMT2020220
Type
Single Phase, 10kA at 120/240V AC
AC
120/240V
Amps
20 A
Phase
Single
Poles
2
For Use With
Homeline Load Center
Max. AIR Rating
10kA at 120/240V AC
AC Voltage Rating
120/240V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D HOMT2020220 is a 20 A, single-phase miniature circuit breaker from the HOM Series, designed for plug-in use with Homeline Load Centers. It has a 120/240V AC voltage rating and a maximum AIR rating of 10kA at 120/240V AC, with 2 poles.

Frequently Asked Questions

What is the SQUARE D HOMT2020220 miniature circuit breaker used for?

The SQUARE D HOMT2020220 is a 20 A, single-phase miniature circuit breaker designed for plug-in use with Homeline Load Centers. It protects electrical circuits from overloads and short circuits in residential and light commercial applications, operating at 120/240V AC with a 10kA interrupting rating.

What are the specifications of the SQUARE D HOMT2020220?

The SQUARE D HOMT2020220 is a 20 A, single-phase, 2-pole miniature circuit breaker with a 120/240V AC voltage rating and a maximum AIR rating of 10kA at 120/240V AC. It is part of the HOM Series and is designed for plug-in use with Homeline Load Centers.

Where to buy the SQUARE D HOMT2020220 worldwide?

3G Electric supplies the SQUARE D HOMT2020220 miniature circuit breaker worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this Square D HOM Series breaker.

How to install the SQUARE D HOMT2020220 in a Homeline Load Center?

To install the SQUARE D HOMT2020220, ensure the load center is de-energized. Align the breaker's plug-in tabs with the bus bar slots in the Homeline Load Center and press firmly until it snaps into place. Always follow local electrical codes and the manufacturer's instructions for safe installation.
