SUBURBAN Angle Plate: Cast Iron, 10 in L x 10 in W x 10 in H, 0.0005 in Square & Parallel - Plain Cast Iron Angle Plates
SUBURBANPlain Cast Iron Angle Plates

SUBURBAN Angle Plate: Cast Iron, 10 in L x 10 in W x 10 in H, 0.0005 in Square & Parallel

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 10 in L x 10 in W x 10 in H. It features a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. This product is identified by…

SKU 3G-OTH-182509

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 10 in L x 10 in W x 10 in H, 0.0005 in Square & Parallel
Category
Plain Cast Iron Angle Plates
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SUBURBAN
Manufacturer Part Number
PAW-101010-G
Type
Ground
H
10 in L x 10 in W x 10 in
Flatness
0.0005 in
Parallelism
0.002 in
Square & Parallel
0.0005 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SUBURBAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 10 in L x 10 in W x 10 in H. It features a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. This product is identified by manufacturer part number PAW-101010-G.

Frequently Asked Questions

What is a SUBURBAN angle plate used for?

A SUBURBAN angle plate is used in precision machining and inspection to hold workpieces at a 90° angle for milling, drilling, or layout. Its ground cast iron construction with 0.0005 in flatness and 0.002 in parallelism ensures accurate squareness for tooling setups and quality control.

What are the specifications of the SUBURBAN PAW-101010-G angle plate?

The SUBURBAN PAW-101010-G is a plain cast iron angle plate measuring 10 in L x 10 in W x 10 in H. It has a ground finish, flatness of 0.0005 in, and parallelism of 0.002 in. Square and parallel tolerance is 0.0005 in. The manufacturer part number is PAW-101010-G.

Where to buy a SUBURBAN angle plate worldwide?

3G Electric supplies the SUBURBAN PAW-101010-G angle plate to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this precision cast iron tool.

How to maintain a SUBURBAN cast iron angle plate?

To maintain a SUBURBAN cast iron angle plate, keep it clean and lightly oiled to prevent rust. Store it on a flat surface away from moisture. Regularly check flatness and parallelism with a surface plate and indicator. Avoid dropping or striking the ground surfaces to preserve accuracy.
