SUBURBAN Angle Plate: Cast Iron, 4 in L x 4 in W x 4 in H, 0.002 in Square & Parallel - Plain Cast Iron Angle Plates
SUBURBANPlain Cast Iron Angle Plates

SUBURBAN Angle Plate: Cast Iron, 4 in L x 4 in W x 4 in H, 0.002 in Square & Parallel

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 4 in L x 4 in W x 4 in H. It is machined to a flatness of 0.002 in and a parallelism of 0.002 in, with the manufacturer part number PAW-040404.

SKU 3G-OTH-182500

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 4 in L x 4 in W x 4 in H, 0.002 in Square & Parallel
Category
Plain Cast Iron Angle Plates
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SUBURBAN
Manufacturer Part Number
PAW-040404
Type
Machined
H
4 in L x 4 in W x 4 in
Flatness
0.002 in
Parallelism
0.002 in
Square & Parallel
0.002 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SUBURBAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 4 in L x 4 in W x 4 in H. It is machined to a flatness of 0.002 in and a parallelism of 0.002 in, with the manufacturer part number PAW-040404.

Frequently Asked Questions

What is a SUBURBAN Angle Plate used for?

A SUBURBAN Angle Plate is used in machining and inspection setups to hold workpieces at a precise 90° angle. It is essential for layout, drilling, milling, and quality-checking squareness on parts, ensuring accuracy in industrial manufacturing and toolroom applications.

What are the specifications of the SUBURBAN Angle Plate PAW-040404?

The SUBURBAN Angle Plate PAW-040404 is cast iron, 4 in L x 4 in W x 4 in H, machined to a flatness of 0.002 in and parallelism of 0.002 in. It is a plain angle plate with a square and parallel tolerance of 0.002 in, suitable for precision workholding.

Where to buy a SUBURBAN Angle Plate worldwide?

3G Electric supplies the SUBURBAN Angle Plate PAW-040404 worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this precision angle plate to your facility, regardless of location. Contact us for availability and lead time.

How to maintain a cast iron angle plate like the SUBURBAN?

To maintain a SUBURBAN cast iron angle plate, keep it clean and lightly oiled to prevent rust. Store it on a flat surface, avoid dropping or striking the machined faces, and periodically check flatness and parallelism with a surface plate and indicator to ensure continued accuracy.

Used in

Common applications for SUBURBAN
Surface grinding setup — SUBURBAN magnetic sine plates (e.g., MSP-126-S2) for angular workpiece positioning
Inspection and quality control — SUBURBAN steel straight edges (e.g., SE-12-TS) for checking flatness of machine tables
Toolroom fixturing — SUBURBAN slotted cast iron angle plates (e.g., SAW-120908) for holding workpieces during milling
Compound angle machining — SUBURBAN compound sine plates (e.g., SPC-1212-S2) for multi-axis angular setups
Precision grinding of small parts — SUBURBAN hardened steel angle plates (e.g., AP-334-S0) with 0.0002 in tolerance for tight-tolerance workholding

SUBURBAN Products

3G Electric supplies SUBURBAN plain cast iron angle plates. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
