SUBURBAN Angle Plate: Cast Iron, 5 in L x 5 in W x 5 in H, 0.0005 in Square & Parallel - Plain Cast Iron Angle Plates
SUBURBANPlain Cast Iron Angle Plates

SUBURBAN Angle Plate: Cast Iron, 5 in L x 5 in W x 5 in H, 0.0005 in Square & Parallel

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 5 in L x 5 in W x 5 in H. It features a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. This product is identified by…

SKU 3G-OTH-182501

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 5 in L x 5 in W x 5 in H, 0.0005 in Square & Parallel
Category
Plain Cast Iron Angle Plates
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SUBURBAN
Manufacturer Part Number
PAW-050505-G
Type
Ground
H
5 in L x 5 in W x 5 in
Flatness
0.0005 in
Parallelism
0.002 in
Square & Parallel
0.0005 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SUBURBAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 5 in L x 5 in W x 5 in H. It features a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. This product is identified by manufacturer part number PAW-050505-G.

Frequently Asked Questions

What is the SUBURBAN Angle Plate used for?

The SUBURBAN Angle Plate is used in precision machining and inspection setups to hold workpieces at a right angle. It is commonly employed in toolrooms, quality control labs, and manufacturing environments for layout, marking, and dimensional verification tasks.

What are the specifications of the SUBURBAN Angle Plate PAW-050505-G?

The SUBURBAN Angle Plate PAW-050505-G is a plain cast iron plate measuring 5 in L x 5 in W x 5 in H. It has a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. The brand is SUBURBAN.

Where to buy the SUBURBAN Angle Plate worldwide?

You can source the SUBURBAN Angle Plate PAW-050505-G through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to maintain a SUBURBAN cast iron angle plate?

To maintain a SUBURBAN cast iron angle plate, keep it clean and lightly oiled to prevent rust. Store it on a flat surface and avoid impacts that could affect flatness or parallelism. Regularly check with a precision straightedge and feeler gauge for wear.
