SUBURBAN Angle Plate: Cast Iron, 3 in L x 3 in W x 3 in H, 0.0005 in Square & Parallel - Plain Cast Iron Angle Plates
SUBURBANPlain Cast Iron Angle Plates

SUBURBAN Angle Plate: Cast Iron, 3 in L x 3 in W x 3 in H, 0.0005 in Square & Parallel

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 3 in L x 3 in W x 3 in H. It features a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. This product is identified by…

SKU 3G-OTH-182497

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 3 in L x 3 in W x 3 in H, 0.0005 in Square & Parallel
Category
Plain Cast Iron Angle Plates
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SUBURBAN
Manufacturer Part Number
PAW-030303-G
Type
Ground
H
3 in L x 3 in W x 3 in
Flatness
0.0005 in
Parallelism
0.002 in
Square & Parallel
0.0005 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SUBURBAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SUBURBAN Angle Plate is a plain cast iron angle plate measuring 3 in L x 3 in W x 3 in H. It features a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. This product is identified by manufacturer part number PAW-030303-G.

Frequently Asked Questions

What is a SUBURBAN Angle Plate used for?

A SUBURBAN Angle Plate is used in precision machining and inspection to hold workpieces at a 90° angle. It is commonly employed in toolrooms, quality control labs, and manufacturing for layout, setup, and measurement tasks requiring high flatness and parallelism.

What are the specifications of the SUBURBAN Angle Plate PAW-030303-G?

The SUBURBAN Angle Plate PAW-030303-G is a plain cast iron plate measuring 3 in L x 3 in W x 3 in H. It has a flatness of 0.0005 in and parallelism of 0.002 in, with a ground finish. The brand is SUBURBAN and the part number is PAW-030303-G.

Where to buy SUBURBAN Angle Plate in worldwide?

You can source the SUBURBAN Angle Plate PAW-030303-G through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to maintain a SUBURBAN cast iron angle plate?

To maintain a SUBURBAN cast iron angle plate, keep it clean and lightly oiled to prevent rust. Store it on a flat surface and avoid impacts that could affect flatness or parallelism. Regularly check with a precision straightedge and feeler gauge to ensure accuracy remains within 0.0005 in flatness.

Used in

Common applications for SUBURBAN
Surface grinding setup — SUBURBAN magnetic sine plates (e.g., MSP-126-S2) for angular workpiece positioning
Inspection and quality control — SUBURBAN steel straight edges (e.g., SE-12-TS) for checking flatness of machine tables
Toolroom fixturing — SUBURBAN slotted cast iron angle plates (e.g., SAW-120908) for holding workpieces during milling
Compound angle machining — SUBURBAN compound sine plates (e.g., SPC-1212-S2) for multi-axis angular setups
Precision grinding of small parts — SUBURBAN hardened steel angle plates (e.g., AP-334-S0) with 0.0002 in tolerance for tight-tolerance workholding

SUBURBAN Products

3G Electric supplies SUBURBAN plain cast iron angle plates. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
