SUBURBAN Angle Plate: Cast Iron, 3 3/4 in L x 4 in W x 5 in H, 0.002 in Square & Parallel - Universal Right-Angle Irons
SUBURBANUniversal Right-Angle Irons

SUBURBAN Angle Plate: Cast Iron, 3 3/4 in L x 4 in W x 5 in H, 0.002 in Square & Parallel

The SUBURBAN Angle Plate is a universal right-angle iron made of cast iron, measuring 3 3/4 in L x 4 in W x 5 in H. It features a square and parallel tolerance of 0.002 in, as specified by the manufacturer. This…

SKU 3G-OTH-207698

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 3 3/4 in L x 4 in W x 5 in H, 0.002 in Square & Parallel
Category
Universal Right-Angle Irons
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SUBURBAN
Manufacturer Part Number
URA-030405
Type
Machined
H
3 3/4 in L x 4 in W x 5 in
Square & Parallel
0.002 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SUBURBAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SUBURBAN Angle Plate is a universal right-angle iron made of cast iron, measuring 3 3/4 in L x 4 in W x 5 in H. It features a square and parallel tolerance of 0.002 in, as specified by the manufacturer. This machined component is designed for precision alignment in industrial setups.

Frequently Asked Questions

What is the SUBURBAN Angle Plate used for?

The SUBURBAN Angle Plate is a universal right-angle iron used for precision alignment and fixturing in industrial setups. It provides a square and parallel reference surface for machining, inspection, and assembly operations, ensuring accurate 90-degree positioning of workpieces.

What are the specifications of the SUBURBAN Angle Plate?

The SUBURBAN Angle Plate (MPN URA-030405) is made of cast iron and measures 3 3/4 in L x 4 in W x 5 in H. It is machined with a square and parallel tolerance of 0.002 in, as specified by the manufacturer SUBURBAN. This ensures high precision for industrial alignment tasks.

Where to buy the SUBURBAN Angle Plate worldwide?

You can source the SUBURBAN Angle Plate worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this precision component.

How to maintain a SUBURBAN Angle Plate?

To maintain the SUBURBAN Angle Plate, keep it clean and lightly oiled to prevent rust on the cast iron surface. Store it on a flat, dry surface and avoid dropping or striking the machined faces. Regularly check the square and parallel tolerance with a precision square to ensure accuracy.

Used in

Common applications for SUBURBAN
Surface grinding setup — SUBURBAN magnetic sine plates (e.g., MSP-126-S2) for angular workpiece positioning
Inspection and quality control — SUBURBAN steel straight edges (e.g., SE-12-TS) for checking flatness of machine tables
Toolroom fixturing — SUBURBAN slotted cast iron angle plates (e.g., SAW-120908) for holding workpieces during milling
Compound angle machining — SUBURBAN compound sine plates (e.g., SPC-1212-S2) for multi-axis angular setups
Precision grinding of small parts — SUBURBAN hardened steel angle plates (e.g., AP-334-S0) with 0.0002 in tolerance for tight-tolerance workholding
