SUBURBAN Angle Plate: Cast Iron, 4 in L x 5 in W x 8 in H, 0.0005 in Square & Parallel - Universal Right-Angle Irons
SUBURBANUniversal Right-Angle Irons

SUBURBAN Angle Plate: Cast Iron, 4 in L x 5 in W x 8 in H, 0.0005 in Square & Parallel

The SUBURBAN Angle Plate is a universal right-angle iron made of cast iron, measuring 4 inches long by 5 inches wide by 8 inches high. It features a square and parallel tolerance of 0.0005 inches and a ground finish…

SKU 3G-OTH-207701

Brand
SUBURBAN
Item
Angle Plate: Cast Iron, 4 in L x 5 in W x 8 in H, 0.0005 in Square & Parallel
Category
Universal Right-Angle Irons
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SUBURBAN
Manufacturer Part Number
URA-040508-G
Type
Ground
H
4 in L x 5 in W x 8 in
Square & Parallel
0.0005 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SUBURBAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SUBURBAN Angle Plate is a universal right-angle iron made of cast iron, measuring 4 inches long by 5 inches wide by 8 inches high. It features a square and parallel tolerance of 0.0005 inches and a ground finish with a 0.00025-inch specification. This product is identified by manufacturer part number URA-040508-G.

Frequently Asked Questions

What is a SUBURBAN angle plate used for?

A SUBURBAN angle plate is a universal right-angle iron used in precision machining and inspection to hold workpieces at a true 90° angle. It is essential for layout, setup, and quality control in toolrooms and manufacturing facilities where squareness and parallelism are critical.

What are the specifications of the SUBURBAN URA-040508-G angle plate?

The SUBURBAN URA-040508-G is a cast iron angle plate measuring 4 in L x 5 in W x 8 in H. It has a ground finish with a square and parallel tolerance of 0.0005 in and a 0.00025 in specification. The manufacturer part number is URA-040508-G.

Where to buy SUBURBAN angle plates worldwide?

3G Electric supplies SUBURBAN angle plates worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver precision tools like the URA-040508-G to your facility. Contact us for availability and lead time.

How to maintain a cast iron angle plate?

To maintain a SUBURBAN cast iron angle plate, keep it clean and lightly oiled to prevent rust. Store it on a flat surface away from moisture. Regularly check squareness and parallelism with a precision square and indicator to ensure the 0.0005 in tolerance is preserved.

Used in

Common applications for SUBURBAN
Surface grinding setup — SUBURBAN magnetic sine plates (e.g., MSP-126-S2) for angular workpiece positioning
Inspection and quality control — SUBURBAN steel straight edges (e.g., SE-12-TS) for checking flatness of machine tables
Toolroom fixturing — SUBURBAN slotted cast iron angle plates (e.g., SAW-120908) for holding workpieces during milling
Compound angle machining — SUBURBAN compound sine plates (e.g., SPC-1212-S2) for multi-axis angular setups
Precision grinding of small parts — SUBURBAN hardened steel angle plates (e.g., AP-334-S0) with 0.0002 in tolerance for tight-tolerance workholding

SUBURBAN Products

3G Electric supplies SUBURBAN universal right-angle irons. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
