TB WOODS TB WOOD'S Sleeve Coupling Flange: 11 Coupling Size, 3,600 RPM Max Speed - Plain Bore Close-Coupled Flanges
TB WOODSPlain Bore Close-Coupled Flanges

TB WOODS TB WOOD'S Sleeve Coupling Flange: 11 Coupling Size, 3,600 RPM Max Speed

The TB WOOD'S Sleeve Coupling Flange, model 11SMPB, is a plain bore close-coupled flange in coupling size 11. It features a round design, an outside diameter of 8 5/8 inches, and a maximum speed of 3,600 RPM, with…

SKU 3G-OTH-141968

Brand
TB WOODS
Item
TB WOOD'S Sleeve Coupling Flange: 11 Coupling Size, 3,600 RPM Max Speed
Category
Plain Bore Close-Coupled Flanges
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TB WOODS
Manufacturer Part Number
11SMPB
Type
Round
Max Speed
3,600 RPM
Outside Dia
8 5/8 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TB WOODS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TB WOOD'S Sleeve Coupling Flange, model 11SMPB, is a plain bore close-coupled flange in coupling size 11. It features a round design, an outside diameter of 8 5/8 inches, and a maximum speed of 3,600 RPM, with dimensions specified in inches.

Frequently Asked Questions

What is the TB WOOD'S 11SMPB sleeve coupling flange used for?

The TB WOOD'S 11SMPB sleeve coupling flange is used to connect two shafts in power transmission systems, typically in industrial machinery such as pumps, conveyors, and compressors. Its close-coupled design allows for a compact, rigid connection in applications requiring reliable torque transfer at speeds up to 3,600 RPM.

What are the specifications of the TB WOOD'S 11SMPB coupling flange?

The TB WOOD'S 11SMPB is a plain bore close-coupled flange in coupling size 11. It has a round design, an outside diameter of 8 5/8 inches, and a maximum speed of 3,600 RPM. Dimensions are in inches. The manufacturer part number is 11SMPB, and it is made by TB WOOD'S.

Where to buy the TB WOOD'S 11SMPB coupling flange worldwide?

You can source the TB WOOD'S 11SMPB coupling flange through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time; we supply genuine TB WOOD'S components for power transmission applications.

How to select the correct TB WOOD'S sleeve coupling flange for an application?

To select the correct TB WOOD'S sleeve coupling flange, match the coupling size (e.g., size 11) to the shaft diameters and torque requirements of your equipment. Verify the maximum speed rating (3,600 RPM for the 11SMPB) and ensure the bore type (plain bore) fits your shaft. Consult TB WOOD'S catalog for dimensional compatibility.

Used in

Common applications for TB WOODS
Pump drives — TB WOOD'S sleeve coupling flanges (e.g., 4J78) for connecting motor to pump shafts in water treatment plants.
Conveyor systems — TB WOOD'S jaw coupling hubs (e.g., L09925MM) for torque transmission in material handling equipment.
Compressor applications — TB WOOD'S tire coupling hubs (e.g., WE2H78) to accommodate misalignment in air compressor drives.
Industrial fans — TB WOOD'S spacer hubs and flanges (e.g., 6SCHMPB, 6SC44) for extended shaft connections in ventilation systems.
Machine tools — TB WOOD'S two-piece sleeve coupling inserts (e.g., model 5) for vibration dampening in spindle drives.
Mixers and agitators — TB WOOD'S finished bore close-coupled flanges for direct coupling in chemical processing equipment.
