THOMAS & BETTS Open Barrel Splice: 1/0 AWG Wire Size, Pink Code, 1.63 in - Crimped Butt Splice Compression Connectors
THOMAS & BETTSCrimped Butt Splice Compression Connectors

THOMAS & BETTS Open Barrel Splice: 1/0 AWG Wire Size, Pink Code, 1.63 in

The THOMAS & BETTS Open Barrel Splice (MPN 54509) is a crimped butt splice compression connector designed for 1/0 AWG wire size. It features a copper barrel, measures 1.63 inches, and uses Die Code 42 with a Pink…

SKU 3G-OTH-17173

Brand
THOMAS & BETTS
Item
Open Barrel Splice: 1/0 AWG Wire Size, Pink Code, 1.63 in
Category
Crimped Butt Splice Compression Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

THOMAS & BETTS
Manufacturer Part Number
54509
Type
Pink Code, 1.63 in, Copper Barrel
Die
42
Die Code
42
Color Code
Pink
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

THOMAS & BETTS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The THOMAS & BETTS Open Barrel Splice (MPN 54509) is a crimped butt splice compression connector designed for 1/0 AWG wire size. It features a copper barrel, measures 1.63 inches, and uses Die Code 42 with a Pink color code for identification.

Frequently Asked Questions

What is the THOMAS & BETTS 54509 open barrel splice used for?

The THOMAS & BETTS 54509 open barrel splice is a crimped butt splice compression connector used to join 1/0 AWG copper wire in industrial electrical installations. It is commonly applied in power distribution, control panels, and heavy machinery wiring where reliable, low-resistance connections are required.

What are the specifications of the THOMAS & BETTS 54509 splice?

The THOMAS & BETTS 54509 open barrel splice is designed for 1/0 AWG wire size, has a copper barrel, measures 1.63 inches, and uses Die Code 42. It is color-coded pink for quick identification. The manufacturer part number is 54509.

Where to buy THOMAS & BETTS 54509 worldwide?

3G Electric supplies the THOMAS & BETTS 54509 open barrel splice to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this compression connector.

How to install the THOMAS & BETTS 54509 open barrel splice?

To install the THOMAS & BETTS 54509 splice, strip 1/0 AWG wire to the barrel depth, insert the wire into the open barrel, and crimp using a compatible tool with Die Code 42. Follow standard compression connector practices to ensure a secure, low-resistance joint. Always verify crimp quality with a pull test.
