TRITAN Sprocket: For 40 Chain, 20 Teeth, 3.196 in Pitch Dia, 3.46 in Outside Dia - Size 40 Bushed-Bore Roller Chain Sprockets
TRITANSize 40 Bushed-Bore Roller Chain Sprockets

TRITAN Sprocket: For 40 Chain, 20 Teeth, 3.196 in Pitch Dia, 3.46 in Outside Dia

The TRITAN Sprocket: For 40 Chain is a Size 40 Bushed-Bore Roller Chain Sprocket, model 40SH20H. It features 20 teeth, a 3.196-inch pitch diameter, and a 3.46-inch outside diameter, constructed from steel. This…

SKU 3G-OTH-125577

Brand
TRITAN
Item
Sprocket: For 40 Chain, 20 Teeth, 3.196 in Pitch Dia, 3.46 in Outside Dia
Category
Size 40 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TRITAN
Manufacturer Part Number
40SH20H
Type
Steel
Teeth
20
Pitch Dia
3.196 in
Outside Dia
3.46 in
Required Bushing Series
SH
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TRITAN Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TRITAN Sprocket: For 40 Chain is a Size 40 Bushed-Bore Roller Chain Sprocket, model 40SH20H. It features 20 teeth, a 3.196-inch pitch diameter, and a 3.46-inch outside diameter, constructed from steel. This sprocket requires an SH bushing series for installation.

Frequently Asked Questions

What is the TRITAN 40SH20H sprocket used for?

The TRITAN 40SH20H sprocket is used in roller chain drive systems to transmit rotary motion between shafts. It is designed for Size 40 chain and is commonly applied in industrial machinery, conveyors, and power transmission equipment where reliable torque transfer is required.

What are the specifications of the TRITAN 40SH20H sprocket?

The TRITAN 40SH20H sprocket has 20 teeth, a 3.196-inch pitch diameter, and a 3.46-inch outside diameter. It is made of steel and requires an SH bushing series for installation. The manufacturer part number is 40SH20H, and it is designed for Size 40 roller chain.

Where to buy the TRITAN 40SH20H sprocket worldwide?

You can source the TRITAN 40SH20H sprocket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this TRITAN sprocket.

How to install the TRITAN 40SH20H sprocket?

To install the TRITAN 40SH20H sprocket, select the correct SH bushing series and bore it to your shaft diameter. Slide the bushing into the sprocket, align the keyway, and tighten the set screws. Ensure proper chain tension and alignment for optimal performance and wear life.
