TSUBAKI Sprocket: For 60 Chain, 60 Teeth, 14.33 in Pitch Dia, 14.761 in Outside Dia - Size 60 Bushed-Bore Roller Chain Sprockets
TSUBAKISize 60 Bushed-Bore Roller Chain Sprockets

TSUBAKI Sprocket: For 60 Chain, 60 Teeth, 14.33 in Pitch Dia, 14.761 in Outside Dia

The TSUBAKI Sprocket is a Size 60 bushed-bore roller chain sprocket designed for 60 chain. It features 60 teeth, a 14.33-inch pitch diameter, and a 14.761-inch outside diameter, constructed from steel. This sprocket…

SKU 3G-OTH-126322

Brand
TSUBAKI
Item
Sprocket: For 60 Chain, 60 Teeth, 14.33 in Pitch Dia, 14.761 in Outside Dia
Category
Size 60 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TSUBAKI
Manufacturer Part Number
60Q60
Type
Steel
Teeth
60
Pitch Dia
14.33 in
Outside Dia
14.761 in
Required Bushing Series
Q1
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TSUBAKI Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TSUBAKI Sprocket is a Size 60 bushed-bore roller chain sprocket designed for 60 chain. It features 60 teeth, a 14.33-inch pitch diameter, and a 14.761-inch outside diameter, constructed from steel. This sprocket requires a Q1 bushing series and is identified by manufacturer part number 60Q60.

Frequently Asked Questions

What is the TSUBAKI 60Q60 sprocket used for?

The TSUBAKI 60Q60 sprocket is used in power transmission systems with Size 60 roller chain. It is commonly applied in industrial machinery, conveyors, and material handling equipment where reliable torque transfer and precise chain engagement are required.

What are the specifications of the TSUBAKI 60Q60 sprocket?

The TSUBAKI 60Q60 sprocket has 60 teeth, a pitch diameter of 14.33 in, and an outside diameter of 14.761 in. It is made of steel and requires a Q1 bushing series. It is designed for 60 chain and carries the manufacturer part number 60Q60.

Where to buy the TSUBAKI 60Q60 sprocket worldwide?

You can source the TSUBAKI 60Q60 sprocket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the sprocket reaches your facility efficiently.

How to select the correct bushing for the TSUBAKI 60Q60 sprocket?

The TSUBAKI 60Q60 sprocket requires a Q1 bushing series. To select the correct bushing, match the shaft diameter to the Q1 bushing bore range and ensure the bushing keyway aligns with your shaft key. Always consult the TSUBAKI catalog for exact dimensions and torque specifications.
