TSUBAKI Sprocket: For 50 Chain, 22 Teeth, 4.392 in Pitch Dia, 4.72 in Outside Dia - Size 50 Bushed-Bore Roller Chain Sprockets
TSUBAKISize 50 Bushed-Bore Roller Chain Sprockets

TSUBAKI Sprocket: For 50 Chain, 22 Teeth, 4.392 in Pitch Dia, 4.72 in Outside Dia

The TSUBAKI Sprocket (SKU 5XYC0) is a Size 50 Bushed-Bore Roller Chain Sprocket designed for 50 chain. It features 22 teeth, a 4.392-inch pitch diameter, and a 4.72-inch outside diameter, constructed from steel. This…

SKU 3G-OTH-134082

Brand
TSUBAKI
Item
Sprocket: For 50 Chain, 22 Teeth, 4.392 in Pitch Dia, 4.72 in Outside Dia
Category
Size 50 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TSUBAKI
Manufacturer Part Number
50SDS22
Type
Steel
Teeth
22
Pitch Dia
4.392 in
Outside Dia
4.72 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TSUBAKI Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TSUBAKI Sprocket (SKU 5XYC0) is a Size 50 Bushed-Bore Roller Chain Sprocket designed for 50 chain. It features 22 teeth, a 4.392-inch pitch diameter, and a 4.72-inch outside diameter, constructed from steel. This model, with manufacturer part number 50SDS22, is identified as the SDS type.

Frequently Asked Questions

What is the TSUBAKI 50SDS22 sprocket used for?

The TSUBAKI 50SDS22 sprocket is used in roller chain drive systems to transmit rotary motion between shafts. It is designed for Size 50 roller chain and is commonly applied in industrial machinery, conveyors, and power transmission equipment where reliable torque transfer is required.

What are the specifications of the TSUBAKI 50SDS22 sprocket?

The TSUBAKI 50SDS22 sprocket has 22 teeth, a 4.392-inch pitch diameter, and a 4.72-inch outside diameter. It is made of steel and is a Size 50 bushed-bore roller chain sprocket. The manufacturer part number is 50SDS22, and it is identified as the SDS type by TSUBAKI.

Where to buy the TSUBAKI 50SDS22 sprocket worldwide?

You can source the TSUBAKI 50SDS22 sprocket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this TSUBAKI sprocket.

How to select the correct TSUBAKI sprocket for a 50 chain?

To select the correct TSUBAKI sprocket for a 50 chain, match the chain size (50), tooth count, and bore type to your application. The 50SDS22 model offers 22 teeth with a bushed-bore design. Ensure the pitch diameter and outside diameter fit your shaft and clearance requirements. Consult TSUBAKI's catalog for compatibility.
