TSUBAKI Sprocket: For 50 Chain, 28 Teeth, 5.582 in Pitch Dia, 5.92 in Outside Dia - Size 50 Bushed-Bore Roller Chain Sprockets
TSUBAKISize 50 Bushed-Bore Roller Chain Sprockets

TSUBAKI Sprocket: For 50 Chain, 28 Teeth, 5.582 in Pitch Dia, 5.92 in Outside Dia

The TSUBAKI Sprocket is a Size 50 Bushed-Bore Roller Chain Sprocket designed for 50 chain, featuring 28 teeth, a 5.582-inch pitch diameter, and a 5.92-inch outside diameter. Constructed from steel, this SDS-series…

SKU 3G-OTH-134038

Brand
TSUBAKI
Item
Sprocket: For 50 Chain, 28 Teeth, 5.582 in Pitch Dia, 5.92 in Outside Dia
Category
Size 50 Bushed-Bore Roller Chain Sprockets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TSUBAKI
Manufacturer Part Number
50SDS28
Type
Steel
Teeth
28
Pitch Dia
5.582 in
Outside Dia
5.92 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TSUBAKI Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TSUBAKI Sprocket is a Size 50 Bushed-Bore Roller Chain Sprocket designed for 50 chain, featuring 28 teeth, a 5.582-inch pitch diameter, and a 5.92-inch outside diameter. Constructed from steel, this SDS-series sprocket (MPN 50SDS28) is manufactured by TSUBAKI for industrial power transmission applications.

Frequently Asked Questions

What is the TSUBAKI 50SDS28 sprocket used for?

The TSUBAKI 50SDS28 sprocket is used in industrial power transmission systems to drive roller chain on conveyors, packaging machinery, and material handling equipment. It is designed for Size 50 roller chain and is suitable for applications requiring reliable torque transfer and precise timing.

What are the specifications of the TSUBAKI 50SDS28 sprocket?

The TSUBAKI 50SDS28 is a steel sprocket with 28 teeth, a 5.582-inch pitch diameter, and a 5.92-inch outside diameter. It is part of the SDS bushed-bore series, designed for Size 50 roller chain. The manufacturer part number is 50SDS28.

Where to buy the TSUBAKI 50SDS28 sprocket worldwide?

You can source the TSUBAKI 50SDS28 sprocket through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the correct TSUBAKI sprocket for a 50 chain?

To select the correct TSUBAKI sprocket for a 50 chain, match the chain size (50), tooth count, and bore type. The 50SDS28 model offers 28 teeth with a bushed bore for flexible mounting. Verify pitch diameter and outside diameter against your drive system requirements. Consult TSUBAKI's catalog for fitment.

Used in

Common applications for TSUBAKI
Material handling conveyors — TSUBAKI C2080H connecting links for heavy-duty chain systems
Packaging machinery — TSUBAKI size 60 roller chains with 60NEPCL connecting links for coated chain applications
Automotive assembly lines — TSUBAKI 80NPSK1CL attachment links for positioning fixtures on single-strand chains
Food processing equipment — TSUBAKI nickel-plated chains and sprockets (e.g., 50BTL48) for washdown environments
General power transmission — TSUBAKI PL1G keyless bushings for shaft mounting without keyways in drive systems
Conveyor drive systems — TSUBAKI 40BTL24 sprockets for size 40 chain in light-to-medium load applications
