WESTWARD Angle Finder: 3 Quadrants, 3 1/2 in Base Lg, Magnetic, Degrees, 3 in Overall Ht - Angle Locators
WESTWARDAngle Locators

WESTWARD Angle Finder: 3 Quadrants, 3 1/2 in Base Lg, Magnetic, Degrees, 3 in Overall Ht

The WESTWARD Angle Finder: 3 Quadrants (SKU 30PA70) is a plastic angle locator made of polystyrene, with a 3 1/2 in base length and 3 in overall height. It features a magnetic base and measures angles from 0° to 90°…

SKU 3G-OTH-305598

Brand
WESTWARD
Item
Angle Finder: 3 Quadrants, 3 1/2 in Base Lg, Magnetic, Degrees, 3 in Overall Ht
Category
Angle Locators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

WESTWARD
Manufacturer Part Number
30PA70
Type
Magnetic, Degrees, 0°to 90°
Base Lg
3 1/2 in
Overall Ht
3 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

WESTWARD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The WESTWARD Angle Finder: 3 Quadrants (SKU 30PA70) is a plastic angle locator made of polystyrene, with a 3 1/2 in base length and 3 in overall height. It features a magnetic base and measures angles from 0° to 90° with a resolution of 0.5°.

Frequently Asked Questions

What is the WESTWARD Angle Finder 30PA70 used for?

The WESTWARD Angle Finder 30PA70 is used for measuring and transferring angles from 0° to 90° in metalworking, woodworking, and fabrication. Its magnetic base attaches to ferrous surfaces for hands-free operation, making it ideal for layout, setup, and inspection tasks in machine shops and construction sites.

What are the specifications of the WESTWARD Angle Finder 30PA70?

The WESTWARD Angle Finder 30PA70 has a 3 1/2 in base length and 3 in overall height. It measures angles from 0° to 90° with a resolution of 0.5°. The body is made of polystyrene plastic, and the base is magnetic. It features three quadrants for versatile angle measurement.

Where to buy the WESTWARD Angle Finder 30PA70 worldwide?

You can source the WESTWARD Angle Finder 30PA70 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide reliable sourcing for this angle locator.

How to maintain the WESTWARD Angle Finder 30PA70?

To maintain the WESTWARD Angle Finder 30PA70, keep the polystyrene body clean and free of debris. Wipe with a dry cloth after use; avoid solvents that may damage plastic. Store in a dry place to prevent rust on the magnetic base. Periodically check the 0.5° scale for readability and the magnet for secure attachment.
