Eaton 3G-OTH-41039 — Technical Specifications

Name: Eaton 3G-OTH-41039 EATON NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 00, 9 A, 24V AC Coil (MPN AN19AN0T5E005). Key specifications — Brand: EATON; Auxiliary Contact Form: 1NO; Coil Voltage: 24V AC; Phase: Three; Operator: None; Operator Controls: None; Auxiliary Contacts Included: 1NO; Signaling Features: Pilot Light.
Brand: Eaton

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 00 unit is rated for 9 A and features a 24V AC coil, a 1NO auxiliary contact, and a pilot light for signaling. It requires no thermal units, as the electronic overload eliminates the need for them.

View Product & Quote

Technical Specifications

Parameter	Value
Type	NEMA Size 00, 9 A
Brand	EATON
Phase	Three
Poles	3
AC Coil	24V
Operator	None
Coil Voltage	24V AC
Operator Controls	None
Signaling Features	Pilot Light
Auxiliary Contact Form	1NO
Thermal Units Required	None (Not Applicable to Electronic Overloads)
Manufacturer Part Number	AN19AN0T5E005
Auxiliary Contacts Included	1NO
