Protec 3G-OTH-22877 — Technical Specifications

Name: Protec 3G-OTH-22877 PROTEC Surge Protection: Single Phase, 120V AC, 2 Poles, 3 Wires, L-G/L-N/N-G, 200 kA (MPN ASISP150-2P). Key specifications — Voltage: 120V AC; Number of Wires: 3 Wires; Modes of Protection: L-G; Max. Continuing Operating Voltage: 150 V AC (L-G); 150 V AC (L-N); 150 V AC (N-G); Voltage Protection Rating: 700V (L-G); Short Circuit Current Rating: 200 kA.
Brand: Protec

The PROTEC Surge Protection: Single Phase (SKU 808CH2) is a DIN Rail internal-mount SPD from PROTEC. It operates at 120V AC with a 200 kA short circuit current rating and a voltage protection rating of 700V (L-G). This 2-pole, 3-wire device provides L-G mode protection and has a max. continuing operating voltage of 150 V AC (L-G).

View Product & Quote

Technical Specifications

Parameter	Value
AC	120V
Type	L-G/L-N/N-G, 200 kA
Brand	PROTEC
Poles	2
Wires	3
Voltage	120V AC
Mounting Style	DIN-Rail
Number Of Wires	3 Wires
Modes Of Protection	L-G
Manufacturer Part Number	ASISP150-2P
Voltage Protection Rating	700V (L-G)
Short Circuit Current Rating	200 kA
Max. Continuing Operating Voltage	150 V AC (L-G)
