PROTEC Surge Protection: Single Phase, 120V AC, 2 Poles, 3 Wires, L-G/L-N/N-G - DIN Rail Internal-Mount SPDs
PROTECDIN Rail Internal-Mount SPDs

PROTEC Surge Protection: Single Phase, 120V AC, 2 Poles, 3 Wires, L-G/L-N/N-G

The PROTEC Surge Protection: Single Phase (SKU 808CH2) is a DIN Rail internal-mount SPD from PROTEC. It operates at 120V AC with a 200 kA short circuit current rating and a voltage protection rating of 700V (L-G)…

SKU 3G-OTH-22877

Brand
PROTEC
Item
Surge Protection: Single Phase, 120V AC, 2 Poles, 3 Wires, L-G/L-N/N-G
Category
DIN Rail Internal-Mount SPDs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

PROTEC
Manufacturer Part Number
ASISP150-2P
Type
L-G/L-N/N-G, 200 kA
AC
120V
Poles
2
Wires
3
Voltage
120V AC
Mounting Style
DIN-Rail
Number of Wires
3 Wires
Modes of Protection
L-G
Voltage Protection Rating
700V (L-G)
Short Circuit Current Rating
200 kA
Max. Continuing Operating Voltage
150 V AC (L-G)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

PROTEC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The PROTEC Surge Protection: Single Phase (SKU 808CH2) is a DIN Rail internal-mount SPD from PROTEC. It operates at 120V AC with a 200 kA short circuit current rating and a voltage protection rating of 700V (L-G). This 2-pole, 3-wire device provides L-G mode protection and has a max. continuing operating voltage of 150 V AC (L-G).

Frequently Asked Questions

What is the PROTEC ASISP150-2P surge protection device used for?

The PROTEC ASISP150-2P is a DIN Rail internal-mount SPD that protects single-phase 120V AC electrical systems from voltage surges. It provides L-G, L-N, and N-G mode protection with a 200 kA short circuit current rating, making it suitable for industrial control panels and equipment.

What are the specifications of the PROTEC ASISP150-2P surge protector?

The PROTEC ASISP150-2P operates at 120V AC with 2 poles and 3 wires. It has a max. continuing operating voltage of 150 V AC (L-G), a voltage protection rating of 700V (L-G), and a short circuit current rating of 200 kA. It mounts on a DIN rail and is part number ASISP150-2P.

Where to buy the PROTEC ASISP150-2P surge protector worldwide?

3G Electric supplies the PROTEC ASISP150-2P surge protector to customers worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this DIN Rail SPD to your facility. Contact us for availability and lead time.

How to install a PROTEC ASISP150-2P DIN Rail surge protector?

Mount the PROTEC ASISP150-2P on a standard DIN rail inside your panel. Connect line, neutral, and ground wires per the L-G/L-N/N-G protection modes. Ensure the system is de-energized before installation. Follow NEC guidelines and the manufacturer's wiring diagram for proper surge protection.

Used in

Common applications for PROTEC
Industrial motor control centers — PROTEC ASISP150-2P SPDs protect VFDs and contactors from transient overvoltages.
HVAC systems — PROTEC DIN-rail SPDs safeguard chiller controls and air handler panels in commercial buildings.
Pump stations — PROTEC ASISP150-1P SPDs provide surge protection for pump control panels in water treatment facilities.
Burner management systems — PROTEC SPDs protect flame safeguard controllers and ignition transformers in industrial burners.
Data acquisition panels — PROTEC SPDs shield PLCs and SCADA equipment from lightning-induced surges in remote monitoring stations.
Lighting control panels — PROTEC SPDs protect dimmer racks and emergency lighting inverters in large facilities.
