EATON Surge Protection Device: Single Phase, 120V AC, 1 Poles, 2 + Ground Wires - DIN Rail Internal-Mount SPDs
EATONDIN Rail Internal-Mount SPDs

EATON Surge Protection Device: Single Phase, 120V AC, 1 Poles, 2 + Ground Wires

The EATON Surge Protection Device (SKU 30UJ06, MPN AGPH12020) is a single-phase, DIN Rail internal-mount SPD with a 120V AC rating. It features N-G mode protection, a 400V (L-N) voltage protection rating, and a 5kA…

SKU 3G-OTH-22851

Brand
EATON
Item
Surge Protection Device: Single Phase, 120V AC, 1 Poles, 2 + Ground Wires
Category
DIN Rail Internal-Mount SPDs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AGPH12020
Type
2 + Ground Wires, L-G/L-N/N-G, 5kA
AC
120V
Poles
1
Voltage
120V AC
Filtering
Yes
Mounting Style
DIN-Rail
Number of Wires
2 Wires + Ground
Enclosure Material
Polycarbonate
Modes of Protection
N-G
Voltage Protection Rating
400V (L-N)
Short Circuit Current Rating
5kA
Max. Continuing Operating Voltage
150 V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON Surge Protection Device (SKU 30UJ06, MPN AGPH12020) is a single-phase, DIN Rail internal-mount SPD with a 120V AC rating. It features N-G mode protection, a 400V (L-N) voltage protection rating, and a 5kA short circuit current rating, with a maximum continuous operating voltage of 150 V AC. This unit supports 2 wires plus ground, includes filtering, and is housed in a polycarbonate enclosure.

Frequently Asked Questions

What is the EATON AGPH12020 surge protection device used for?

The EATON AGPH12020 is a single-phase, DIN Rail internal-mount SPD that protects 120V AC electrical panels from transient overvoltages. It is used in industrial control cabinets, HVAC systems, and building automation to safeguard sensitive equipment against surges on L-N and N-G modes.

What are the specifications of the EATON AGPH12020?

The EATON AGPH12020 is a 120V AC, 1-pole SPD with a 5kA short circuit current rating and a 400V (L-N) voltage protection rating. It supports 2 wires plus ground, has a maximum continuous operating voltage of 150 V AC, includes filtering, and is housed in a polycarbonate enclosure.

Where to buy the EATON AGPH12020 worldwide?

3G Electric supplies the EATON AGPH12020 surge protection device to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this DIN Rail SPD.

How to install the EATON AGPH12020 on a DIN rail?

To install the EATON AGPH12020, snap the SPD onto a standard DIN rail in your electrical panel. Connect the line, neutral, and ground wires per the wiring diagram, ensuring the 120V AC supply is off. Follow NEC guidelines for SPD installation and verify the 5kA short circuit rating matches your system.
