APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, M10-1.00 Thread Size, Plain - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, M10-1.00 Thread Size, Plain

The APPROVED VENDOR Helical Insert is a free-running tanged tang style insert with M10-1.00 thread size, fine pitch, right-hand orientation, and plain finish. Made from 18-8 metal, it offers 200,000 psi tensile…

SKU 3G-OTH-599140

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Free-Running, M10-1.00 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3523-10.00X2.0D
Type
Free-Running, M10-1.00 Thread Size, Plain, 10 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a free-running tanged tang style insert with M10-1.00 thread size, fine pitch, right-hand orientation, and plain finish. Made from 18-8 metal, it offers 200,000 psi tensile strength and comes in a 10-pack (MPN 3523-10.00X2.0D).

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or reinforces tapped threads in metal. This free-running tanged tang style, M10-1.00 fine pitch, is used in automotive, machinery, and industrial equipment to restore stripped threads or strengthen connections in 18-8 metal up to 200,000 psi tensile strength.

What are the specifications of the APPROVED VENDOR helical insert 3523-10.00X2.0D?

This helical insert is free-running with a tanged tang, M10-1.00 thread size, fine pitch, right-hand orientation, and plain finish. It is made from 18-8 metal with 200,000 psi tensile strength. The 10-pack includes MPN 3523-10.00X2.0D, metric sizing, and is suitable for metal substrates.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to source this M10-1.00 free-running insert or other thread repair components across 14 industrial departments.

How to install a tanged tang helical insert?

To install a tanged tang helical insert, drill to the specified tap drill size, tap the hole with the correct thread pitch (M10-1.00 fine), then use a tang installation tool to wind the insert into the tapped hole. Break off the tang after installation. Always follow the manufacturer's torque and depth guidelines for 18-8 metal.
