APPROVED VENDOR Self Locking Thread Insert: Std Wall, 3/8"-16 Int Thrd Sz, 1 in Overall Lg - Heavy Wall Self-Locking Inserts
APPROVED VENDORHeavy Wall Self-Locking Inserts

APPROVED VENDOR Self Locking Thread Insert: Std Wall, 3/8"-16 Int Thrd Sz, 1 in Overall Lg

The APPROVED VENDOR Self Locking Thread Insert is a heavy wall, standard wall type insert with a 3/8"-16 internal coarse thread and 1-inch overall length. Supplied as a 5-pack (MPN 329-601-PK5), it requires a 31/64…

SKU 3G-OTH-534116

Brand
APPROVED VENDOR
Item
Self Locking Thread Insert: Std Wall, 3/8"-16 Int Thrd Sz, 1 in Overall Lg
Category
Heavy Wall Self-Locking Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
329-601-PK5
Type
5 PK
Overall Lg
1 in
Wall Type
Standard Wall
Int Thrd Sz
3/8"-16
Thread Type
Coarse
Drill Bit Size
31/64
Compatible Tap Size
9/16"-12
External Thread Fit
2A
Internal Thread Fit
2B
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Self Locking Thread Insert is a heavy wall, standard wall type insert with a 3/8"-16 internal coarse thread and 1-inch overall length. Supplied as a 5-pack (MPN 329-601-PK5), it requires a 31/64 drill bit and a 9/16"-12 compatible tap, with external thread fit 2A and internal thread fit 2B in inch measurement.

Frequently Asked Questions

What is an APPROVED VENDOR Self Locking Thread Insert used for?

This heavy wall insert repairs or reinforces tapped holes in metal assemblies, preventing thread stripping under vibration. It is commonly used in industrial machinery, automotive, and equipment maintenance where a 3/8"-16 coarse thread is required.

What are the specifications of the APPROVED VENDOR 329-601-PK5 thread insert?

The insert has a 3/8"-16 internal coarse thread, 1-inch overall length, standard wall type, and requires a 31/64 drill bit with a 9/16"-12 compatible tap. External thread fit is 2A, internal fit is 2B, and it is supplied as a 5-pack.

Where to buy APPROVED VENDOR thread inserts in worldwide?

3G Electric supplies APPROVED VENDOR self-locking thread inserts worldwide. We handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on the 329-601-PK5 5-pack.

How to install an APPROVED VENDOR self-locking thread insert?

Drill a hole using a 31/64 bit, tap it with a 9/16"-12 tap, then install the insert using a compatible tool. The self-locking feature secures the insert without adhesives. Follow standard thread insert installation practices for best results.
