APPROVED VENDOR Helical Inserts: Tanged Tang Style, Free-Running, M16x2 Thread Size - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Inserts: Tanged Tang Style, Free-Running, M16x2 Thread Size

APPROVED VENDOR Helical Inserts: Tanged Tang Style are free-running, M16x2 thread size, 5 PK helical inserts made of 304 chromium nickel metal with a right-hand coarse thread, 14 mm length, and 200,000 psi tensile…

SKU 3G-OTH-599068

Brand
APPROVED VENDOR
Item
Helical Inserts: Tanged Tang Style, Free-Running, M16x2 Thread Size
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
5WZR5
Type
Free-Running, M16x2 Thread Size, 5 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

APPROVED VENDOR Helical Inserts: Tanged Tang Style are free-running, M16x2 thread size, 5 PK helical inserts made of 304 chromium nickel metal with a right-hand coarse thread, 14 mm length, and 200,000 psi tensile strength. These inserts are designed for metric M16-2.00 thread repair or reinforcement in metal applications.

Frequently Asked Questions

What are APPROVED VENDOR helical inserts used for?

APPROVED VENDOR helical inserts are used to repair or reinforce internal threads in metal components. The M16x2 free-running tanged style provides a strong 304 chromium nickel thread that resists wear and corrosion, ideal for industrial machinery, automotive, and heavy equipment applications.

What are the specifications of APPROVED VENDOR M16x2 helical inserts?

These helical inserts are free-running, tanged style, M16-2.00 thread size, 14 mm length, right-hand coarse thread, made of 304 chromium nickel metal with 200,000 psi tensile strength. Sold in a 5-pack under MPN 5WZR5 by APPROVED VENDOR.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the M16x2 free-running tanged style inserts (MPN 5WZR5) for your thread repair needs.

How to install APPROVED VENDOR tanged helical inserts?

To install, drill the hole to the specified tap drill size, tap threads with the correct M16x2 tap, then insert the helical insert using a tang installation tool. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for proper thread engagement and torque.
