ASHCROFT Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1130, 3 1/2 in Dial - Medium & High Operating Pressure Differential Gauges
ASHCROFTMedium & High Operating Pressure Differential Gauges

ASHCROFT Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1130, 3 1/2 in Dial

The ASHCROFT Differential Pressure Gauge: In-Line is a medium and high operating pressure differential gauge from the Series 1130. It features a diaphragm sensor, an aluminum housing, and a 3 1/2 in dial with 1/4 in…

SKU 3G-OTH-175112

Brand
ASHCROFT
Item
Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1130, 3 1/2 in Dial
Category
Medium & High Operating Pressure Differential Gauges
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
351130FD25SXCYLM30PSID
Series
1130
Type
1130, Aluminum
Dial
3 1/2 in
NPT Female
1/4 in
Sensor Type
Diaphragm
Housing Material
Aluminum
Certificate of Calibration
Not Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT Differential Pressure Gauge: In-Line is a medium and high operating pressure differential gauge from the Series 1130. It features a diaphragm sensor, an aluminum housing, and a 3 1/2 in dial with 1/4 in NPT female connections. This model (MPN 351130FD25SXCYLM30PSID) does not include a certificate of calibration.

Frequently Asked Questions

What is the ASHCROFT 1130 differential pressure gauge used for?

The ASHCROFT 1130 differential pressure gauge is used to measure the difference in pressure between two points in industrial fluid or gas systems. It is suitable for medium and high operating pressure applications, such as filtration monitoring, pump performance, and flow measurement in process plants.

What are the specifications of the ASHCROFT 1130 differential pressure gauge?

The ASHCROFT 1130 differential pressure gauge features a diaphragm sensor, aluminum housing, and a 3 1/2 in dial with 1/4 in NPT female connections. It is part of the Series 1130 and does not include a certificate of calibration. The model number is 351130FD25SXCYLM30PSID.

Where to buy the ASHCROFT 1130 differential pressure gauge worldwide?

You can source the ASHCROFT 1130 differential pressure gauge through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this model.

How to install the ASHCROFT 1130 differential pressure gauge?

Install the ASHCROFT 1130 differential pressure gauge by connecting the 1/4 in NPT female ports to the high- and low-pressure lines. Ensure the diaphragm sensor is not over-ranged. Use proper thread sealant and mount the gauge in a vibration-free location. Refer to the manufacturer's manual for torque and orientation guidelines.
