ASHCROFT Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1132, 3 1/2 in Dial - Medium & High Operating Pressure Differential Gauges
ASHCROFTMedium & High Operating Pressure Differential Gauges

ASHCROFT Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1132, 3 1/2 in Dial

The ASHCROFT Differential Pressure Gauge: In-Line is a medium and high operating pressure differential gauge from the 1132 series. It features a diaphragm sensor type and an aluminum housing, with a 3 1/2 in dial and…

SKU 3G-OTH-175093

Brand
ASHCROFT
Item
Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1132, 3 1/2 in Dial
Category
Medium & High Operating Pressure Differential Gauges
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
351132FD25SXCYLM200IWD
Series
1132
Type
1132, Aluminum
Dial
3 1/2 in
NPT Female
1/4 in
Sensor Type
Diaphragm
Housing Material
Aluminum
Certificate of Calibration
Not Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT Differential Pressure Gauge: In-Line is a medium and high operating pressure differential gauge from the 1132 series. It features a diaphragm sensor type and an aluminum housing, with a 3 1/2 in dial and 1/4 in NPT female connections (MPN 351132FD25SXCYLM200IWD). Certificate of calibration is not included.

Frequently Asked Questions

What is the ASHCROFT 1132 differential pressure gauge used for?

The ASHCROFT 1132 differential pressure gauge measures the difference between two pressure points in industrial fluid or gas systems. It is commonly used in filtration, pump monitoring, and flow measurement applications where medium to high operating pressures are present.

What are the specifications of the ASHCROFT 1132 differential pressure gauge?

This ASHCROFT 1132 gauge has a 3 1/2 in dial, 1/4 in NPT female connections, a diaphragm sensor, and an aluminum housing. It is designed for medium and high operating pressure differentials. The MPN is 351132FD25SXCYLM200IWD. Certificate of calibration is not included.

Where to buy the ASHCROFT 1132 differential pressure gauge worldwide?

3G Electric supplies the ASHCROFT 1132 differential pressure gauge worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this diaphragm-type differential pressure gauge.

How to install the ASHCROFT 1132 differential pressure gauge?

Install the ASHCROFT 1132 gauge using the 1/4 in NPT female connections with compatible pipe thread sealant. Mount the gauge in a location free from excessive vibration and within its rated pressure range. Always depressurize the system before installation and follow standard industrial instrumentation practices.
