ASHCROFT Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1132, 3 1/2 in Dial - Medium & High Operating Pressure Differential Gauges
ASHCROFTMedium & High Operating Pressure Differential Gauges

ASHCROFT Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1132, 3 1/2 in Dial

The ASHCROFT Differential Pressure Gauge: In-Line is a medium and high operating pressure differential gauge from the 1132 series. It features a 3 1/2 in dial, 1/4 in NPT female connections, a diaphragm sensor type…

SKU 3G-OTH-175088

Brand
ASHCROFT
Item
Differential Pressure Gauge: In-Line, 1/4 in NPT Female, 1132, 3 1/2 in Dial
Category
Medium & High Operating Pressure Differential Gauges
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
351132FD25SXCYLM100IWD
Series
1132
Type
1132, Aluminum
Dial
3 1/2 in
NPT Female
1/4 in
Sensor Type
Diaphragm
Housing Material
Aluminum
Certificate of Calibration
Not Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT Differential Pressure Gauge: In-Line is a medium and high operating pressure differential gauge from the 1132 series. It features a 3 1/2 in dial, 1/4 in NPT female connections, a diaphragm sensor type, and an aluminum housing. This model (MPN 351132FD25SXCYLM100IWD) does not include a certificate of calibration.

Frequently Asked Questions

What is the ASHCROFT 1132 differential pressure gauge used for?

The ASHCROFT 1132 differential pressure gauge is used to measure the difference in pressure between two points in industrial fluid systems. It is suitable for medium and high operating pressure applications, such as monitoring filter condition, pump performance, or flow across valves in process plants.

What are the specifications of the ASHCROFT 1132 differential pressure gauge?

The ASHCROFT 1132 differential pressure gauge has a 3 1/2 in dial, 1/4 in NPT female connections, a diaphragm sensor type, and an aluminum housing. It does not include a certificate of calibration. The model number is 351132FD25SXCYLM100IWD.

Where to buy the ASHCROFT 1132 differential pressure gauge worldwide?

You can source the ASHCROFT 1132 differential pressure gauge through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the ASHCROFT 1132 differential pressure gauge?

Install the ASHCROFT 1132 gauge by connecting the 1/4 in NPT female ports to the process lines, ensuring proper sealing with thread tape. Mount the gauge in a location free from excessive vibration. Refer to the manufacturer's manual for specific torque and orientation guidelines.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi
