ASHCROFT Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female - Low Operating Pressure Differential Gauges with Switch
ASHCROFTLow Operating Pressure Differential Gauges with Switch

ASHCROFT Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female

The ASHCROFT Differential Pressure Gauge & Switch is a low operating pressure differential gauge with switch, featuring a diaphragm sensor and ±3% gauge accuracy. This Series 1134 model has a glass filled nylon…

SKU 3G-OTH-175312

Brand
ASHCROFT
Item
Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female
Category
Low Operating Pressure Differential Gauges with Switch
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
451134EDRQMXV5CYLM2IWD
Series
1134
Type
1134, IP65
NPT Female
1/8 in
Sensor Type
Diaphragm
Gauge Accuracy
±3%
Housing Material
Glass Filled Nylon
Certificate of Calibration
Not Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT Differential Pressure Gauge & Switch is a low operating pressure differential gauge with switch, featuring a diaphragm sensor and ±3% gauge accuracy. This Series 1134 model has a glass filled nylon housing and 1/8 in NPT female connections, rated IP65. It is designed for dual in-line or back mounting and does not include a certificate of calibration.

Frequently Asked Questions

What is the ASHCROFT 1134 differential pressure gauge with switch used for?

The ASHCROFT 1134 differential pressure gauge with switch is used for low operating pressure monitoring and control in HVAC, filtration, and process applications. It provides a local readout and switch output for alarm or shutdown, with a diaphragm sensor and ±3% gauge accuracy.

What are the specifications of the ASHCROFT 1134 differential pressure gauge with switch?

The ASHCROFT 1134 differential pressure gauge with switch features a diaphragm sensor, ±3% gauge accuracy, glass filled nylon housing, and 1/8 in NPT female connections. It is rated IP65, supports dual in-line or back mounting, and does not include a certificate of calibration.

Where to buy the ASHCROFT 1134 differential pressure gauge with switch worldwide?

You can source the ASHCROFT 1134 differential pressure gauge with switch from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the product reaches your facility reliably.

How to install the ASHCROFT 1134 differential pressure gauge with switch?

Install the ASHCROFT 1134 differential pressure gauge with switch by mounting it in-line or back using the 1/8 in NPT female ports. Ensure the diaphragm sensor is not overpressured beyond its rated range. Use proper sealing on threads and verify electrical connections for the switch output per local codes.
