ASHCROFT Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female - Low Operating Pressure Differential Gauges with Switch
ASHCROFTLow Operating Pressure Differential Gauges with Switch

ASHCROFT Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female

The ASHCROFT Differential Pressure Gauge & Switch is a low operating pressure differential gauge with switch, featuring a diaphragm sensor and ±3% gauge accuracy. It has a glass filled nylon housing and is available…

SKU 3G-OTH-175315

Brand
ASHCROFT
Item
Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female
Category
Low Operating Pressure Differential Gauges with Switch
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
451134EDRQMXV5CYLM5IWD
Series
1134
Type
1134, IP65
NPT Female
1/8 in
Sensor Type
Diaphragm
Gauge Accuracy
±3%
Housing Material
Glass Filled Nylon
Certificate of Calibration
Not Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT Differential Pressure Gauge & Switch is a low operating pressure differential gauge with switch, featuring a diaphragm sensor and ±3% gauge accuracy. It has a glass filled nylon housing and is available in dual in-line or back configurations with 1/8 in NPT Female connections. This Series 1134 model is rated IP65 and does not include a certificate of calibration.

Frequently Asked Questions

What is the ASHCROFT 1134 differential pressure gauge and switch used for?

The ASHCROFT 1134 differential pressure gauge with switch is used for low operating pressure monitoring and control in HVAC, filtration, and process applications. It provides local indication and switching for filter monitoring, flow measurement, and pump protection where a diaphragm sensor and ±3% accuracy are sufficient.

What are the specifications of the ASHCROFT 1134 differential pressure gauge and switch?

The ASHCROFT 1134 features a diaphragm sensor, ±3% gauge accuracy, glass filled nylon housing, and 1/8 in NPT female connections in dual in-line or back configurations. It is rated IP65 and does not include a certificate of calibration. The manufacturer part number is 451134EDRQMXV5CYLM5IWD.

Where to buy the ASHCROFT 1134 differential pressure gauge and switch worldwide?

3G Electric supplies the ASHCROFT 1134 differential pressure gauge and switch worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this Series 1134 model.

How to install the ASHCROFT 1134 differential pressure gauge and switch?

Install the ASHCROFT 1134 by mounting it in-line or back-connected using 1/8 in NPT female ports. Ensure the diaphragm sensor is not over-pressured beyond rated limits. Use proper thread sealant and avoid overtightening. For switch wiring, follow the terminal diagram on the IP65 housing. Calibration is not included.
