ASHCROFT Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female - Low Operating Pressure Differential Gauges with Switch
ASHCROFTLow Operating Pressure Differential Gauges with Switch

ASHCROFT Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female

The ASHCROFT Differential Pressure Gauge & Switch, model 451134EDRQMXV5CYLM3IWD from Series 1134, is a low operating pressure differential gauge with a switch. It features a diaphragm sensor, ±3% gauge accuracy, and…

SKU 3G-OTH-175305

Brand
ASHCROFT
Item
Differential Pressure Gauge & Switch: Dual In-Line or Back, 1/8 in NPT Female
Category
Low Operating Pressure Differential Gauges with Switch
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
451134EDRQMXV5CYLM3IWD
Series
1134
Type
1134, IP65
NPT Female
1/8 in
Sensor Type
Diaphragm
Gauge Accuracy
±3%
Housing Material
Glass Filled Nylon
Certificate of Calibration
Not Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT Differential Pressure Gauge & Switch, model 451134EDRQMXV5CYLM3IWD from Series 1134, is a low operating pressure differential gauge with a switch. It features a diaphragm sensor, ±3% gauge accuracy, and a glass filled nylon housing with IP65 protection. The unit has 1/8 in NPT Female connections and is available in dual in-line or back configurations.

Frequently Asked Questions

What is the ASHCROFT 1134 differential pressure gauge with switch used for?

The ASHCROFT 1134 differential pressure gauge with switch is used to measure and control low differential pressure in HVAC, filtration, and process systems. Its diaphragm sensor and IP65-rated glass filled nylon housing suit clean or mildly corrosive environments where reliable switching at low pressure is needed.

What are the specifications of the ASHCROFT 451134EDRQMXV5CYLM3IWD?

This ASHCROFT Series 1134 differential pressure gauge and switch has a diaphragm sensor, ±3% gauge accuracy, and 1/8 in NPT Female connections. The housing is glass filled nylon with IP65 protection. It is available in dual in-line or back configurations. Certificate of calibration is not included.

Where to buy the ASHCROFT 1134 differential pressure gauge worldwide?

3G Electric supplies the ASHCROFT 1134 differential pressure gauge worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time. We source and deliver this model to any country.

How to install the ASHCROFT 1134 differential pressure gauge with switch?

Mount the gauge using the 1/8 in NPT Female connections in either in-line or back configuration. Ensure the diaphragm sensor is not over-pressured beyond its rated range. Use appropriate sealant on threads. Wire the switch per the manufacturer's diagram. Protect the IP65 housing from direct water jets.
