Beckett CG15 Gas Burner 560 to 1,500 MBH | AC Power
Beckett CG15 gas burner delivering 560–1,500 MBH output for commercial heating, steam generation, and industrial applications with advanced combustion control and flexible fuel compatibility.
SKU 3G-BKT-00071
Also listed as: CG151S · CG15 1S · CG15-1S
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Beckett CG15 gas burner delivering 560–1,500 MBH output for commercial heating, steam generation, and industrial applications with advanced combustion control and flexible fuel compatibility.
Frequently Asked Questions
What is the Beckett CG15 gas burner used for?
The Beckett CG15 gas burner is used for commercial heating, steam generation, and industrial process applications. It delivers 560–1,500 MBH output and is suitable for natural gas or propane systems requiring reliable combustion control.
What are the specifications of the Beckett CG15 gas burner?
The Beckett CG15 burner features a 1/2 HP, 3450 RPM motor at 120V, 1 ph, 60 Hz, 6.4 Amps. It has a firing rate of 350–1,500 MBH (US) and 560–1,370 MBH (Canada). It is UL Listed with CSD-1 configuration and supports optional voltages up to 575V 3ph.
Where to buy the Beckett CG15 gas burner in Singapore?
You can source the Beckett CG15 gas burner through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this commercial burner for your heating or steam application.
How to install the Beckett CG15 gas burner?
Install the Beckett CG15 burner by ensuring proper gas pressure between 3.7" WC and 10 PSI, and correct voltage (120V standard). Follow the manual for flamerod flame detection setup and combustion air adjustments. Always comply with local codes and use a qualified technician.
Key Features
- Firing range: 560–1,500 MBH (US); 560–1,370 MBH (Canada)
- 1/2 HP motor, 3450 RPM; 120V single-phase standard
- Optional voltages: 208/230V 1ph, 208/230V 3ph, 460V 3ph, 575V 3ph
- Direct spark ignition with flamerod detection (UV optional)
- Full modulation support accepting 135 ohm, 4–20 mA, or 0–10 VAC inputs
- Cast aluminum chassis for durability and noise reduction
- Linkage-less air damper for simplified adjustment
- Removable gas gun assembly for straightforward maintenance
- Right or left hand gas train connection options
- UL/cUL and CSD-1 certified; optional IRI and FM approvals
- Maximum gas pressure: 10 PSI; minimum: 3.7" WC
- Operates on natural gas (0.6 SG) and propane (1.53 SG)
- Power On and Fuel On indicator lights
- Junction box with terminal strip for quick installation
