Beckett CG50 Gas Burner 1,400 to 5,000 MBH | AC Power
Beckett CG50 gas burner delivers 1,400–5,000 MBH firing capacity for commercial heating, steam generation, and industrial food processing applications with advanced combustion control and UV flame detection.
SKU 3G-BKT-00073
Also listed as: CG501S · CG50 1S · CG50-1S
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Beckett CG50 gas burner delivers 1,400–5,000 MBH firing capacity for commercial heating, steam generation, and industrial food processing applications with advanced combustion control and UV flame detection.
Frequently Asked Questions
What is the Beckett CG50 gas burner used for?
The Beckett CG50 gas burner is used for commercial heating, steam generation, and industrial food processing applications. It delivers 1,400 to 5,000 MBH firing capacity with advanced combustion control and UV flame detection, making it suitable for large-scale process heating and boiler systems.
What are the specifications of the Beckett CG50 gas burner?
The Beckett CG50 features a 2 HP, 3450 RPM motor, operates on 208/230V, 1 ph, 60 Hz, 13.4 Amps, and supports optional voltages including 208/230V 3ph, 460V 3ph, and 575V 3ph. It is UL Listed with CSD-1 configuration, uses UV flame detection, and has a firing rate of 730–5,000 MBH (US) or 1,400–4,000 MBH (Canada).
Where to buy the Beckett CG50 gas burner in Singapore?
You can source the Beckett CG50 gas burner through 3G Electric in Singapore. We supply this burner and handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on availability.
How to install the Beckett CG50 gas burner?
Installation of the Beckett CG50 should follow the manufacturer's manual and local codes. Ensure proper gas pressure (3.5" WC minimum, 10 PSI maximum) and electrical supply matching the motor specs. Use a qualified technician for combustion setup and UV flame detector alignment to ensure safe operation.
Key Features
- 2 HP motor, 3450 RPM with 208/230V single-phase power (optional 3-phase and 460V/575V)
- Firing range: 730–5,000 MBH (US); 1,400–4,000 MBH (Canada)
- Dual-fuel operation: natural gas and propane with independent specific gravity tuning
- UV flame detection with direct spark ignition
- Cast aluminum construction for durability and noise reduction
- Linkage-free air damper adjustment for simplified commissioning
- Full modulation capability: accepts 135Ω, 4–20 mA, or 0–10 VAC signals
- UL/cUL Listed and CSD-1 compliant
- Quick-disconnect gas gun assembly for rapid service and maintenance
- Flexible gas train connection: right or left-hand orientation
- Integrated junction box with terminal strip for faster installation
- Power On and Fuel On indicator lights standard
- Optional FM and IRI approvals available
- Ventless gas train configuration
