Beckett CG25 Gas Burner 990 to 2,700 MBH | AC Power
Beckett CG25 gas burner delivers 990–2,700 MBH output for commercial heating, steam generation, and food processing applications with advanced combustion control and flexible voltage options.
SKU 3G-BKT-00072
Also listed as: CG251S · CG25 1S · CG25-1S
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Beckett CG25 gas burner delivers 990–2,700 MBH output for commercial heating, steam generation, and food processing applications with advanced combustion control and flexible voltage options.
Frequently Asked Questions
What is the Beckett CG25 gas burner used for?
The Beckett CG25 gas burner is used for commercial heating, steam generation, and food processing applications. It delivers 990 to 2,700 MBH output with advanced combustion control, making it suitable for industrial boilers and process heaters requiring reliable, high-capacity gas firing.
What are the specifications of the Beckett CG25 gas burner?
The Beckett CG25 burner features a 3/4 HP, 3450 RPM motor, 120V 1ph 60 Hz supply (10.4 Amps), and optional voltages including 208/230V and 460V 3ph. It uses UV flame detection, supports natural gas (0.6 specific gravity) or propane (1.53 specific gravity), and has a firing rate of 990–2,700 MBH (US) or 990–2,300 MBH (Canada).
Where to buy the Beckett CG25 gas burner in Singapore?
You can source the Beckett CG25 gas burner through 3G Electric in Singapore. We supply this burner and handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this commercial gas burner.
How to select the right Beckett CG25 gas burner configuration?
To select the correct Beckett CG25 configuration, verify your required firing rate (990–2,700 MBH), available voltage (120V to 575V), and fuel type (natural gas or propane). Choose between high/low controls (RM7897C) or modulation controls (RM7840L). Confirm gas pressure meets minimum 3.5" WC and maximum 10 PSI. Consult a combustion engineer for application-specific setup.
Key Features
- Firing range: 990–2,700 MBH (US) / 990–2,300 MBH (Canada)
- 3/4 HP motor at 3,450 RPM with 120V single-phase standard
- UL Listed and CSD-1 certified for commercial/industrial use
- UV flame detection with direct spark ignition
- Optional full modulation accepting 135 ohm, 4–20 mA, or 0–10 VAC inputs
- Cast aluminum housing for durability and noise reduction
- Linkage-free air damper adjustment for simplified operation
- Removable gas gun assembly enables quick service and maintenance
- Gas pressure range: 3.5" WC minimum to 10 PSI maximum
- Compatible with natural gas (0.6 SG) and propane (1.53 SG)
- Optional voltages: 208/230V single/three-phase, 460V, 575V three-phase
- Right or left hand gas train connection flexibility
- Standard Power On and Fuel On indicator lights
- Terminal strip junction box for straightforward wiring installation
