Beckett CF2500A Oil Burner 17.00 to 19.90 GPH | AC Power
High-efficiency oil burner engineered for commercial heating and steam applications, delivering 17-19.90 GPH with advanced combustion control and multiple voltage options.
SKU 3G-BKT-00063
Also listed as: BCF 3001 · BCF-3001
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
High-efficiency oil burner engineered for commercial heating and steam applications, delivering 17-19.90 GPH with advanced combustion control and multiple voltage options.
Frequently Asked Questions
What is the Beckett CF2500A oil burner used for?
The Beckett CF2500A is a high-efficiency oil burner designed for commercial heating and steam boiler applications. It delivers 17.00 to 19.90 GPH and is suitable for industrial facilities requiring reliable combustion control.
What are the specifications of the Beckett CF2500A oil burner?
The Beckett CF2500A oil burner has a firing rate of 17.00 to 19.90 GPH and supports optional voltages of 208, 230, 480, or 575 VAC three-phase at 50 or 60 Hz. It is engineered for commercial heating and steam applications.
Where to buy the Beckett CF2500A oil burner in Singapore?
You can source the Beckett CF2500A oil burner through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this commercial oil burner.
How to install the Beckett CF2500A oil burner?
Installation of the Beckett CF2500A oil burner should follow the manufacturer's manual and local codes. Ensure proper fuel supply, electrical connections matching the voltage (208–575 VAC three-phase), and combustion air adjustments. Always use a qualified technician for commissioning.
Key Features
- Dual nozzle design operating at 250-300 PSI for optimized fuel atomization
- Direct spark ignition for reliable cold starts
- Cast aluminum housing for durability and reduced noise
- Linkageless air damper adjustment for simplified operation
- 2 HP burner motor with 240V/60Hz single-phase standard
- Optional three-phase support: 208, 230, 480, or 575 VAC
- UL/cUL and CSD-1 certified for safety and performance
- Biodiesel blend compatible up to B20 (D396 certified)
- Integrated power and fuel status indicator lights
- Pre-wired junction box with terminal strip for quick installation
- Burner-mounted control panels available
- Proven combustion technology for high-efficiency heating
