BeckettDiesel burners
Beckett CF1400 Oil Burner 4.00 to 13.60 GPH | AC Power
Beckett CF1400 oil burner for commercial heating and industrial applications. Delivers 4–13.6 GPH capacity with direct spark ignition and efficient combustion technology.
SKU 3G-BKT-00062
Also listed as: BCF 205 · BCF-205
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineerNo account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h
Not sure this is the right part? Get a recommendation.
Need installation or engineering help?
Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineerAsk a question
Beckett Products
3G Electric (S) Pte. Ltd. — Singapore
Product Description
Beckett CF1400 oil burner for commercial heating and industrial applications. Delivers 4–13.6 GPH capacity with direct spark ignition and efficient combustion technology.
Key Features
- 4.00 to 13.60 GPH fuel flow capacity for flexible load requirements
- Direct spark ignition system for reliable startup
- Linkageless air damper adjustment with dual-stage nozzle operation (125–150 PSI low fire, 250–300 PSI high fire)
- Cast aluminum housing delivers quiet, robust performance
- 1/2 HP burner motor with standard 110V/60Hz supply
- Multiple voltage options: 240V single-phase or 208/240/480V three-phase available
- UL/cUL certified for safety compliance
- Power On and Fuel On indicator lights included
- Easy-access junction box with terminal strip for quick installation
- Biodiesel-compatible (B6–B20 blends per D396 standard)
- CSD-1 control option available for enhanced modulation
- Proven combustion technology for high-efficiency operation
Used in
Common applications for BeckettAmerican-spec food-processing boiler burners — AFG scheduled-maintenance parts
Institutional kitchen and cafeteria plant — SF series for 3–7 GPH continuous duty
Commercial gas / dual-fuel — CG10 / CG15 / CG25 for medium-scale installations
Marine and offshore auxiliary plant — Beckett semi-commercial oil burners
Retrofit swap from ageing Italian burners where customer prefers American-style simpler service catalog
