Beckett CF375 Oil Burner 1.65 to 3.75 GPH | AC Power
Beckett CF375 oil burner for commercial heating and industrial applications. Delivers 1.65–3.75 GPH with direct spark ignition and cast aluminum construction for reliable, quiet operation.
SKU 3G-BKT-00065
Also listed as: BCF 3907 · BCF-3907
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Beckett CF375 oil burner for commercial heating and industrial applications. Delivers 1.65–3.75 GPH with direct spark ignition and cast aluminum construction for reliable, quiet operation.
Frequently Asked Questions
What is the Beckett CF375 oil burner used for?
The Beckett CF375 oil burner is used for commercial heating and industrial applications, including boilers, furnaces, and air handlers. It delivers 1.65 to 3.75 GPH and burns No. 1 or No. 2 heating oil, as well as B6–B20 biodiesel blends, making it suitable for medium-to-large heating systems.
What are the specifications of the Beckett CF375 oil burner?
The Beckett CF375 oil burner has a firing rate of 1.65 to 3.75 GPH, a 1/7 HP 3450 RPM PSC motor at 120/60 Hz, and a cast aluminum housing. It uses a 120V/12,000V ignition transformer, a fuel unit rated 100 to 200 psig, and accepts 45° to 70° solid oil nozzles.
Where to buy the Beckett CF375 oil burner in Singapore?
You can source the Beckett CF375 oil burner through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this commercial oil burner.
How to install the Beckett CF375 oil burner?
Install the Beckett CF375 oil burner by mounting it securely to the appliance, connecting the fuel line from the pump (100–200 psig), wiring the 120 VAC motor and ignition transformer, and setting the nozzle and electrode gaps per the manual. Always follow local codes and the manufacturer's instructions.
Key Features
- Flow rate: 1.65 to 3.75 GPH
- Direct spark ignition system
- 120V, 1/7 HP PSC motor
- Cast aluminum housing for durability and noise reduction
- UL/cUL certified for safety compliance
- Biodiesel blend compatible up to B20 (D396 certified)
- Two-pipe oil delivery system with return line
- Simple on/off operation
- Remote-mounted control panel options available
- Welded insertion design for secure appliance integration
