Beckett CF2500 Oil Burner 17.00 to 25.00 GPH | AC Power
Beckett CF2500 oil burner delivers 17-25 GPH capacity for commercial heating and steam applications. Features direct spark ignition, dual nozzles, and linkageless air damper adjustment for efficient light industrial use.
SKU 3G-BKT-00061
Also listed as: BCF 1809 · BCF-1809
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Beckett CF2500 oil burner delivers 17-25 GPH capacity for commercial heating and steam applications. Features direct spark ignition, dual nozzles, and linkageless air damper adjustment for efficient light industrial use.
Frequently Asked Questions
What is the Beckett CF2500 oil burner used for?
The Beckett CF2500 oil burner is designed for commercial heating and steam applications, delivering 17 to 25 GPH capacity for light industrial use. It features direct spark ignition and dual nozzles for reliable performance in boilers and furnaces.
What are the specifications of the Beckett CF2500 oil burner?
The Beckett CF2500 oil burner has a firing rate of 17.00 to 25.00 GPH and supports optional voltages of 208, 230, 480, or 575 VAC three-phase at 50 or 60 Hz. It includes direct spark ignition, dual nozzles, and linkageless air damper adjustment.
Where to buy the Beckett CF2500 oil burner in Singapore?
You can source the Beckett CF2500 oil burner through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this commercial heating component.
How to install the Beckett CF2500 oil burner?
Install the Beckett CF2500 oil burner by mounting it securely to the boiler or furnace, connecting the fuel line to the dual nozzles, and wiring the three-phase power per the voltage rating. Follow the manufacturer's manual for air damper adjustment and ignition setup.
Key Features
- Direct spark ignition for reliable startup
- Dual nozzles operating at 250-300 PSI
- Linkageless air damper adjustment system
- Cast aluminum housing for durability and quiet operation
- 2 HP burner motor
- Standard 240V/60Hz/1-phase; optional 208-240-480V/3-phase configurations
- Power On and Fuel On indicator lights
- Pre-wired junction box with terminal strip
- UL/cUL and CSD-1 certified
- Compatible with biodiesel blends up to 20% (D396 B6-B20)
- Suitable for steam generation and heated pressure washing
Used in
Common applications for BeckettBeckett Products
3G Electric supplies Beckett diesel burners. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
