Beckett CF1000 Oil Burner 4.00 to 10.00 GPH | AC Power
Beckett CF1000 oil burner delivers efficient combustion for commercial heating, steam generation, and pressure washing applications with flexible voltage configurations and robust cast aluminum construction.
SKU 3G-BKT-00059
Also listed as: BCF 101 · BCF-101
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Beckett CF1000 oil burner delivers efficient combustion for commercial heating, steam generation, and pressure washing applications with flexible voltage configurations and robust cast aluminum construction.
Frequently Asked Questions
What is the Beckett CF1000 oil burner used for?
The Beckett CF1000 oil burner is designed for commercial heating, steam generation, and pressure washing applications. It delivers efficient combustion with a firing range of 4.00 to 10.00 GPH, making it suitable for industrial boilers and process heating systems.
What are the specifications of the Beckett CF1000 oil burner?
The Beckett CF1000 oil burner offers optional voltages including 240 VAC/1-PH and 208, 240, 480 VAC/3-PH at 60 Hz or 50 Hz. It features robust cast aluminum construction and a firing range of 4.00 to 10.00 GPH for commercial heating and steam generation.
Where to buy the Beckett CF1000 oil burner in Singapore?
3G Electric supplies the Beckett CF1000 oil burner to Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact our team to place an order or request a quote for this commercial oil burner.
How to install the Beckett CF1000 oil burner?
Installation of the Beckett CF1000 oil burner should follow the manufacturer's manual and local codes. Ensure proper fuel supply, electrical connections matching the voltage configuration, and secure mounting. Always have a qualified technician perform the setup for safe operation.
Key Features
- Direct spark ignition with power-on and fuel-on indicator lights
- Cast aluminum housing for durability and noise reduction
- 1/2 HP motor with standard 110V/60Hz operation
- Optional voltages: 240V single-phase, 208-240-480V three-phase
- UL/cUL certified with CSD-1 control option available
- Two-pipe oil circulation system with return line
- Junction box with terminal strip for simplified wiring
- Biodiesel blend compatible up to 20% (B6-B20 certified)
- Remote mounted control panel capability
- Proven combustion technology for light commercial and industrial use
Used in
Common applications for BeckettBeckett Products
3G Electric supplies Beckett diesel burners. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
