Beckett CF500 Oil Burner 1.75 to 5.50 GPH | AC Power

Beckett CF500 oil burner for commercial heating and industrial applications. Efficient 1.75–5.50 GPH capacity with direct spark ignition and cast aluminum construction.

SKU 3G-BKT-00025

Also listed as: 400 · 4 00 · 4-00

Brand
Beckett
Item
CF500 Oil Burner 1.75 to 5.50 GPH
Category
Diesel burners
UNSPSC
40101834 — Burners
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Beckett
Rate
1.75 to 5.50 GPH
Fuels
No. 1 or No. 2 heating oil (ASTM D396); ASTM D396 for B6 – B20 biodiesel blends
Motor
1/3 HP 3450 rpm, 120/60 Hz Standard, 4.8 amps @ 120 VAC
Housing
Cast aluminum
Fuel Unit
100 to 200 psig
Operation
On/Off
Oil Nozzle
45˚ to 70˚ Solid
Ignition Trans.
120V/14,000V
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Beckett Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

Beckett CF500 oil burner for commercial heating and industrial applications. Efficient 1.75–5.50 GPH capacity with direct spark ignition and cast aluminum construction.

Key Features

  • 1.75 to 5.50 GPH fuel capacity range
  • Direct spark ignition for reliable startup
  • 120V AC motor, 1/3 HP standard
  • Cast aluminum chassis for durability and noise reduction
  • UL/cUL certified construction
  • Biodiesel compatible—supports B6 to B20 blends
  • Two-pipe oil flow system with integrated pump
  • CSD-1 control option available
  • Remote-mounted control panel compatible
  • Designed for light commercial and industrial heating applications

Used in

Common applications for Beckett
American-spec food-processing boiler burners — AFG scheduled-maintenance parts
Institutional kitchen and cafeteria plant — SF series for 3–7 GPH continuous duty
Commercial gas / dual-fuel — CG10 / CG15 / CG25 for medium-scale installations
Marine and offshore auxiliary plant — Beckett semi-commercial oil burners
Retrofit swap from ageing Italian burners where customer prefers American-style simpler service catalog

Beckett Products

3G Electric supplies Beckett diesel burners. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
