Dayton Exhaust Fan: 24 in Blade - Belt-Drive Panel Exhaust Fans without Drive Package
DaytonBelt-Drive Panel Exhaust Fans without Drive Package

Dayton Exhaust Fan: 24 in Blade

The Dayton 1AHA8 is an unassembled belt-drive panel exhaust fan with a 24-inch cast aluminum blade. It is constructed with a steel frame featuring a zinc-plated finish and is supplied without intake guards. This fan…

SKU 3G-OTH-83688

Brand
Dayton
Item
Exhaust Fan: 24 in Blade
Category
Belt-Drive Panel Exhaust Fans without Drive Package
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1AHA8
Type
For 5,608 cfm to 8,115 cfm Air Flow (Dependent on Motor)
Assembled
Unassembled
Guard Type
None
Frame Finish
Zinc-Plated
Blade Material
Cast Aluminum
Frame Material
Steel
Guard Type Subheads
Without Intake Guards
Method of Construction
Cast
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 1AHA8 is an unassembled belt-drive panel exhaust fan with a 24-inch cast aluminum blade. It is constructed with a steel frame featuring a zinc-plated finish and is supplied without intake guards. This fan delivers an airflow range of 5,608 cfm to 8,115 cfm, dependent on the motor selected.

Frequently Asked Questions

What is the Dayton 1AHA8 exhaust fan used for?

The Dayton 1AHA8 is a belt-drive panel exhaust fan designed for industrial ventilation, moving 5,608 to 8,115 cfm depending on the motor. It is commonly used in factories, warehouses, and commercial buildings to remove heat, fumes, or stale air, improving air quality and worker comfort.

What are the specifications of the Dayton 1AHA8 exhaust fan?

The Dayton 1AHA8 has a 24-inch cast aluminum blade, a steel frame with zinc-plated finish, and is unassembled without intake guards. Airflow ranges from 5,608 cfm to 8,115 cfm, dependent on the motor selected. It is a cast-construction belt-drive panel fan, MPN 1AHA8.

Where to buy the Dayton 1AHA8 exhaust fan worldwide?

3G Electric supplies the Dayton 1AHA8 exhaust fan worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this fan to any country.

How to install the Dayton 1AHA8 exhaust fan?

Install the Dayton 1AHA8 by mounting the unassembled panel securely to a wall or roof opening, ensuring structural support. Select a compatible motor and drive package (not included), then connect wiring per local codes. Follow generic belt-drive fan best practices for alignment and tensioning to ensure safe operation.
