Dayton Timing Belt: One Side, Curvilinear, Synchro-Link, 14 mm Pitch, 40 mm Top Wd
The DAYTON Timing Belt: One Side is an HTD Section Timing Belt from the Synchro-Link® series, identified by Industry Number 1190-14M-40. This curvilinear belt features a 14 mm pitch and a 40 mm top width, as…
SKU 3G-OTH-118028
Need installation or engineering help?
Ask a question
Product Description
The DAYTON Timing Belt: One Side is an HTD Section Timing Belt from the Synchro-Link® series, identified by Industry Number 1190-14M-40. This curvilinear belt features a 14 mm pitch and a 40 mm top width, as specified by the manufacturer part number 1LWB5.
Frequently Asked Questions
What is the DAYTON 1190-14M-40 timing belt used for?
The DAYTON 1190-14M-40 is a curvilinear HTD section timing belt from the Synchro-Link® series. It is used for synchronous power transmission in industrial machinery, conveyors, and automation systems where precise timing and high torque are required.
What are the specifications of the DAYTON 1LWB5 timing belt?
The DAYTON 1LWB5 timing belt has an industry number of 1190-14M-40, a 14 mm pitch, and a 40 mm top width. It is a one-side, curvilinear Synchro-Link® belt designed for HTD section applications.
Where to buy the DAYTON 1190-14M-40 timing belt worldwide?
You can source the DAYTON 1190-14M-40 timing belt through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring reliable supply for your operations.
How to select the correct DAYTON timing belt for my application?
To select the correct DAYTON timing belt, match the industry number (e.g., 1190-14M-40) to your drive system's pitch and width requirements. Ensure the belt's curvilinear profile and HTD section align with your pulley design for proper engagement and load capacity.
Used in
Common applications for DaytonDayton Products
3G Electric supplies Dayton htd section timing belts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
