Dayton Timing Belt: One Side, Curvilinear, Synchro-Link, 14 mm Pitch, 115 mm Top Wd - HTD Section Timing Belts
DaytonHTD Section Timing Belts

Dayton Timing Belt: One Side, Curvilinear, Synchro-Link, 14 mm Pitch, 115 mm Top Wd

The DAYTON Timing Belt: One Side is an HTD Section Timing Belt from the Synchro-Link® series, identified by Industry Number 1890-14M-115 and MPN 1LWD6. It features a curvilinear tooth profile with a 14 mm pitch and a…

SKU 3G-OTH-124441

Brand
Dayton
Item
Timing Belt: One Side, Curvilinear, Synchro-Link, 14 mm Pitch, 115 mm Top Wd
Category
HTD Section Timing Belts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1LWD6
Type
Curvilinear, Synchro-Link®, 1890-14M-115
Pitch
14 mm
Top Wd
115 mm
Industry Number
1890-14M-115
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Belt: One Side is an HTD Section Timing Belt from the Synchro-Link® series, identified by Industry Number 1890-14M-115 and MPN 1LWD6. It features a curvilinear tooth profile with a 14 mm pitch and a 115 mm top width. This belt is designed for synchronous power transmission applications requiring precise timing.

Frequently Asked Questions

What is the DAYTON 1890-14M-115 timing belt used for?

The DAYTON 1890-14M-115 Synchro-Link® timing belt is used for synchronous power transmission in industrial machinery requiring precise timing, such as conveyors, packaging equipment, and machine tools. Its curvilinear tooth profile and 14 mm pitch ensure positive engagement and reduced backlash.

What are the specifications of the DAYTON 1LWD6 timing belt?

The DAYTON 1LWD6 timing belt has a curvilinear Synchro-Link® design with a 14 mm pitch and 115 mm top width. It is an HTD section belt identified by Industry Number 1890-14M-115. This belt is designed for high-torque synchronous drive applications requiring accurate positioning.

Where to buy the DAYTON 1890-14M-115 timing belt worldwide?

3G Electric supplies the DAYTON 1890-14M-115 timing belt worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this Synchro-Link® belt.

How to select the correct DAYTON timing belt for an application?

To select the correct DAYTON timing belt, match the pitch (14 mm), top width (115 mm), and belt length (1890 mm) to your drive system's pulley specifications. Ensure the curvilinear tooth profile aligns with your HTD pulleys. Consult the drive design manual for power ratings and tensioning guidelines.
