Dayton Timing Belt: One Side, Curvilinear, Synchro-Link, 14 mm Pitch, 55 mm Top Wd
The DAYTON Timing Belt: One Side is an HTD Section Timing Belt, model 1190-14M-55 (MPN 1LWB6). It features a curvilinear, Synchro-Link® design with a 14 mm pitch and 55 mm top width.
SKU 3G-OTH-148882
Need installation or engineering help?
Ask a question
Product Description
The DAYTON Timing Belt: One Side is an HTD Section Timing Belt, model 1190-14M-55 (MPN 1LWB6). It features a curvilinear, Synchro-Link® design with a 14 mm pitch and 55 mm top width.
Frequently Asked Questions
What is the DAYTON 1190-14M-55 timing belt used for?
The DAYTON 1190-14M-55 is a curvilinear Synchro-Link® timing belt used in industrial power transmission applications requiring precise synchronization, such as conveyors, packaging machinery, and automated manufacturing lines.
What are the specifications of the DAYTON 1LWB6 timing belt?
The DAYTON 1LWB6 timing belt is an HTD section belt with a 14 mm pitch, 55 mm top width, and curvilinear Synchro-Link® design. Its model number is 1190-14M-55, and it is designed for one-side drive applications.
Where to buy the DAYTON 1190-14M-55 timing belt worldwide?
3G Electric supplies the DAYTON 1190-14M-55 timing belt worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this belt to your facility, regardless of location.
How to select the correct DAYTON timing belt for my application?
To select the correct DAYTON timing belt, match the pitch (14 mm), top width (55 mm), and belt length (1190 mm) to your drive system's pulley specifications. Ensure the curvilinear Synchro-Link® profile aligns with your HTD pulleys for proper engagement.
Used in
Common applications for DaytonDayton Products
3G Electric supplies Dayton htd section timing belts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
