Dayton Rotary Gear Pump Head: Direct Drive, Bronze, 1/2" FNPT, PPS, 304 SS - C-Face Mount Gear Pump Heads
DaytonC-Face Mount Gear Pump Heads

Dayton Rotary Gear Pump Head: Direct Drive, Bronze, 1/2" FNPT, PPS, 304 SS

The DAYTON Rotary Gear Pump Head: Direct Drive (MPN 4KHC2) is a C-face mount gear pump head designed for 56C motor frame sizes. This bronze pump head features 1/2" FNPT ports, includes a relief valve, and is…

SKU 3G-OTH-93114

Brand
Dayton
Item
Rotary Gear Pump Head: Direct Drive, Bronze, 1/2" FNPT, PPS, 304 SS
Category
C-Face Mount Gear Pump Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4KHC2
Type
Bronze, PPS
SS
304
FNPT
1/2"
Ports
1/2" FNPT
SUS Max. Viscosity
500
For Motor Frame Size
56C
Includes Relief Valve
Yes
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Rotary Gear Pump Head: Direct Drive (MPN 4KHC2) is a C-face mount gear pump head designed for 56C motor frame sizes. This bronze pump head features 1/2" FNPT ports, includes a relief valve, and is constructed with PPS and 304 SS materials, supporting a maximum viscosity of 500 SUS.

Frequently Asked Questions

What is the DAYTON 4KHC2 rotary gear pump head used for?

The DAYTON 4KHC2 rotary gear pump head is used for transferring clean, non-abrasive fluids in industrial applications such as lubrication, hydraulic systems, and chemical processing. It handles fluids up to 500 SUS viscosity and is designed for direct-drive C-face mounting on a 56C motor frame.

What are the specifications of the DAYTON 4KHC2 gear pump head?

The DAYTON 4KHC2 is a direct-drive rotary gear pump head with bronze and PPS construction, 304 SS components, and 1/2" FNPT ports. It includes a relief valve, supports a maximum viscosity of 500 SUS, and fits a 56C motor frame. The manufacturer part number is 4KHC2.

Where to buy the DAYTON 4KHC2 gear pump head worldwide?

3G Electric supplies the DAYTON 4KHC2 gear pump head worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this bronze rotary gear pump head.

How to install the DAYTON 4KHC2 C-face mount gear pump head?

To install the DAYTON 4KHC2, mount the pump head directly onto a 56C motor frame using the C-face flange. Ensure the shaft alignment is correct and the ports are connected with 1/2" FNPT fittings. Always follow the manufacturer's manual for torque specs and relief valve adjustment.
