Dayton Rotary Gear Pump Head: Direct Drive, Cast Iron, 1" FNPT, Steel, SS - C-Face Mount Gear Pump Heads
DaytonC-Face Mount Gear Pump Heads

Dayton Rotary Gear Pump Head: Direct Drive, Cast Iron, 1" FNPT, Steel, SS

The DAYTON Rotary Gear Pump Head: Direct Drive is a C-Face mount gear pump head designed for motor frame size 182TC. This cast-iron unit features 1" FNPT ports, includes a relief valve, and handles fluids up to 500…

SKU 3G-OTH-93173

Brand
Dayton
Item
Rotary Gear Pump Head: Direct Drive, Cast Iron, 1" FNPT, Steel, SS
Category
C-Face Mount Gear Pump Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4KHC9
Type
Cast Iron, Steel, SS
FNPT
1"
Ports
1" FNPT
SUS Max. Viscosity
500
For Motor Frame Size
182TC
Includes Relief Valve
Yes
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Rotary Gear Pump Head: Direct Drive is a C-Face mount gear pump head designed for motor frame size 182TC. This cast-iron unit features 1" FNPT ports, includes a relief valve, and handles fluids up to 500 SUS maximum viscosity. It is constructed with steel and stainless steel components.

Frequently Asked Questions

What is the DAYTON Rotary Gear Pump Head 4KHC9 used for?

The DAYTON Rotary Gear Pump Head 4KHC9 is used for transferring fluids in industrial applications. It handles fluids up to 500 SUS maximum viscosity, making it suitable for oils, lubricants, and other non-corrosive liquids. The cast-iron construction with steel and stainless steel components ensures durability in demanding environments.

What are the specifications of the DAYTON 4KHC9 gear pump head?

The DAYTON 4KHC9 is a C-Face mount rotary gear pump head for motor frame size 182TC. It has 1" FNPT ports, includes a relief valve, and handles fluids up to 500 SUS maximum viscosity. The pump head is made of cast iron with steel and stainless steel internals. The manufacturer part number is 4KHC9.

Where to buy the DAYTON 4KHC9 gear pump head worldwide?

You can source the DAYTON 4KHC9 gear pump head through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time. 3G Electric supplies this DAYTON pump head to customers across multiple industries.

How to select the right motor for the DAYTON 4KHC9 pump head?

Select a motor with frame size 182TC to match the DAYTON 4KHC9 C-Face mount. Ensure the motor shaft and coupling align with the pump's direct-drive design. Verify the motor's power rating and speed meet your flow and pressure requirements. Consult the pump's viscosity rating of 500 SUS max to confirm fluid compatibility.
