Dayton Rotary Gear Pump Head: Direct Drive, Cast Iron, 1/4" FNPT, Steel, SS - C-Face Mount Gear Pump Heads
DaytonC-Face Mount Gear Pump Heads

Dayton Rotary Gear Pump Head: Direct Drive, Cast Iron, 1/4" FNPT, Steel, SS

The DAYTON Rotary Gear Pump Head: Direct Drive (SKU 4KHC5) is a C-Face mount gear pump head designed for motor frame size 56C. This cast iron unit features 1/4" FNPT ports, includes a relief valve, and handles fluids…

SKU 3G-OTH-92998

Brand
Dayton
Item
Rotary Gear Pump Head: Direct Drive, Cast Iron, 1/4" FNPT, Steel, SS
Category
C-Face Mount Gear Pump Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4KHC5
Type
Cast Iron, Steel, SS
FNPT
1/4"
Ports
1/4" FNPT
SUS Max. Viscosity
500
For Motor Frame Size
56C
Includes Relief Valve
Yes
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Rotary Gear Pump Head: Direct Drive (SKU 4KHC5) is a C-Face mount gear pump head designed for motor frame size 56C. This cast iron unit features 1/4" FNPT ports, includes a relief valve, and handles fluids with a maximum viscosity of 500 SUS.

Frequently Asked Questions

What is the DAYTON Rotary Gear Pump Head 4KHC5 used for?

The DAYTON Rotary Gear Pump Head 4KHC5 is used for transferring fluids with a maximum viscosity of 500 SUS. It is commonly applied in industrial lubrication, hydraulic systems, and fluid handling where a direct-drive, C-Face mount pump head is needed.

What are the specifications of the DAYTON 4KHC5 gear pump head?

The DAYTON 4KHC5 is a cast iron rotary gear pump head with 1/4" FNPT ports, designed for a 56C motor frame. It includes a relief valve and handles fluids up to 500 SUS viscosity. The manufacturer part number is 4KHC5.

Where to buy the DAYTON 4KHC5 gear pump head worldwide?

You can source the DAYTON 4KHC5 gear pump head through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time.

How to install the DAYTON 4KHC5 gear pump head?

Mount the DAYTON 4KHC5 directly to a 56C motor frame using the C-Face design. Ensure the 1/4" FNPT ports are properly aligned and sealed. The integrated relief valve protects against overpressure. Follow standard pump installation practices for alignment and piping support.
