Dayton Rotary Gear Pump Head: Direct Drive, Cast Iron, 3/8" FNPT, Steel, SS - Carbonator Mount Gear Pump Heads
DaytonCarbonator Mount Gear Pump Heads

Dayton Rotary Gear Pump Head: Direct Drive, Cast Iron, 3/8" FNPT, Steel, SS

The DAYTON Rotary Gear Pump Head: Direct Drive (MPN 4KHR2) is a carbonator mount gear pump head constructed with a cast iron body and steel/SS internals. It features 3/8" FNPT ports, is designed for a 48 motor frame…

SKU 3G-OTH-93203

Brand
Dayton
Item
Rotary Gear Pump Head: Direct Drive, Cast Iron, 3/8" FNPT, Steel, SS
Category
Carbonator Mount Gear Pump Heads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
4KHR2
Type
Cast Iron, Steel, SS
FNPT
3/8"
Ports
3/8" FNPT
SUS Max. Viscosity
500
For Motor Frame Size
48
Includes Relief Valve
Yes
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Rotary Gear Pump Head: Direct Drive (MPN 4KHR2) is a carbonator mount gear pump head constructed with a cast iron body and steel/SS internals. It features 3/8" FNPT ports, is designed for a 48 motor frame size, and includes a relief valve. This unit handles fluids up to 500 SUS max viscosity.

Frequently Asked Questions

What is the DAYTON Rotary Gear Pump Head 4KHR2 used for?

The DAYTON Rotary Gear Pump Head 4KHR2 is a carbonator mount gear pump head used for transferring and circulating fluids in industrial carbonation systems. It handles fluids up to 500 SUS max viscosity and is suitable for applications requiring a direct-drive pump with a cast iron body and steel/SS internals.

What are the specifications of the DAYTON 4KHR2 gear pump head?

The DAYTON 4KHR2 is a direct-drive rotary gear pump head with a cast iron body and steel/SS internals. It has 3/8" FNPT ports, includes a relief valve, and is designed for a 48 motor frame size. Maximum fluid viscosity is 500 SUS. The manufacturer part number is 4KHR2.

Where to buy the DAYTON 4KHR2 gear pump head worldwide?

You can source the DAYTON 4KHR2 gear pump head worldwide through 3G Electric. As a global industrial equipment distributor, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this DAYTON pump head.

How to install the DAYTON 4KHR2 gear pump head?

To install the DAYTON 4KHR2 gear pump head, mount it to a compatible 48-frame motor using the direct-drive coupling. Connect 3/8" FNPT piping to the ports and ensure the relief valve is properly set. Always follow standard pump installation practices and consult the manufacturer's manual for torque and alignment specifications.
