Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water - Suspended Horizontal Hydronic Wall & Ceiling Unit Heaters
DaytonSuspended Horizontal Hydronic Wall & Ceiling Unit Heaters

Dayton Hydronic Wall and Ceiling Unit Heater: Steam/Water

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 5PV16) is a suspended horizontal unit heater designed for steam heating. It delivers an air flow of 1.800 cfm and features a 1-1/2 in threaded female NPT…

SKU 3G-OTH-65805

Brand
Dayton
Item
Hydronic Wall and Ceiling Unit Heater: Steam/Water
Category
Suspended Horizontal Hydronic Wall & Ceiling Unit Heaters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
5PV16
Type
78,400 BtuH Output @ 200 F Water
Air Flow
1.800 cfm
Fan Guard Type
OSHA Compliant Guard
Heating Method
Steam
Overall Dimensions - H x W x D
24 in x 19-5/8 in x 13-13/16 in
Connection Size, Connection Type
1-1/2 in, Threaded Female NPT
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Hydronic Wall and Ceiling Unit Heater (SKU 5PV16) is a suspended horizontal unit heater designed for steam heating. It delivers an air flow of 1.800 cfm and features a 1-1/2 in threaded female NPT connection. The unit includes an OSHA Compliant Guard and has overall dimensions of 24 in x 19-5/8 in x 13-13/16 in.

Frequently Asked Questions

What is the DAYTON Hydronic Wall and Ceiling Unit Heater used for?

The DAYTON Hydronic Wall and Ceiling Unit Heater is used for steam heating in commercial and industrial spaces. It delivers 78,400 BtuH output at 200°F water and 1,800 cfm airflow, making it suitable for warehouses, factories, and large open areas requiring suspended horizontal heating.

What are the specifications of the DAYTON 5PV16 unit heater?

The DAYTON 5PV16 unit heater has a heating output of 78,400 BtuH at 200°F water, airflow of 1,800 cfm, and a 1-1/2 in threaded female NPT connection. It includes an OSHA-compliant fan guard and measures 24 in x 19-5/8 in x 13-13/16 in. It is designed for steam heating applications.

Where to buy the DAYTON 5PV16 unit heater worldwide?

You can source the DAYTON 5PV16 unit heater through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive sourcing for this Dayton steam heater.

How to install a DAYTON hydronic unit heater?

Install the DAYTON hydronic unit heater suspended horizontally from a ceiling or wall using appropriate mounting brackets. Connect the 1-1/2 in threaded female NPT supply and return lines for steam. Ensure the OSHA-compliant fan guard is secure. Follow local codes and the manufacturer's manual for electrical and piping connections.
