Dayton Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity - IEC Thermal Overload Relays
DaytonIEC Thermal Overload Relays

Dayton Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity

The DAYTON Overload Relay: Thermal Protection (SKU 6ECC1) is an IEC thermal overload relay with three poles and integrated bimetallic elements, eliminating the need for separate thermal units. It features 1NO/1NC…

SKU 3G-OTH-39701

Brand
Dayton
Item
Overload Relay: Thermal Protection, 3 Poles, 1NO/1NC, Phase Loss Sensitivity
Category
IEC Thermal Overload Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
6ECC1
Type
1NO/1NC, Phase Loss Sensitivity, 4 A – 6 A
Poles
3
Compatible Contactors
Dayton (9 to 18 Amp Models)
Auxiliary Contact Form
1NO/1NC
Phase Loss Sensitivity
Yes
Thermal Units Required
None (Relay Includes Integrated Bimetallic Elements)
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Overload Relay: Thermal Protection (SKU 6ECC1) is an IEC thermal overload relay with three poles and integrated bimetallic elements, eliminating the need for separate thermal units. It features 1NO/1NC auxiliary contacts and phase loss sensitivity, and is compatible with Dayton contactors in the 9 to 18 Amp models. The relay is adjustable for a current range of 4 A to 6 A.

Frequently Asked Questions

What is the DAYTON Overload Relay 6ECC1 used for?

The DAYTON Overload Relay 6ECC1 provides thermal protection for three-phase motors by monitoring current and tripping on overload or phase loss. It is used in industrial motor control panels, conveyors, pumps, and HVAC equipment to prevent motor damage from excessive heat or unbalanced supply.

What are the specifications of the DAYTON Overload Relay 6ECC1?

The DAYTON Overload Relay 6ECC1 is an IEC thermal overload relay with 3 poles, 1NO/1NC auxiliary contacts, and phase loss sensitivity. It has an adjustable current range of 4 A to 6 A and includes integrated bimetallic elements, so no separate thermal units are required. It is compatible with Dayton contactors rated 9 to 18 Amps.

Where to buy the DAYTON Overload Relay 6ECC1 worldwide?

You can source the DAYTON Overload Relay 6ECC1 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine DAYTON components for motor protection applications.

How to select the correct DAYTON Overload Relay for a motor?

To select the correct DAYTON overload relay, match the relay's adjustable current range to the motor's full-load amperage. For the 6ECC1, set the dial between 4 A and 6 A. Ensure the relay's contactor compatibility matches your Dayton contactor model (9 to 18 Amp). Always verify phase loss sensitivity is required for your application.
